pellet granules material charger magnetic vibrating feeder
- 500 Set / Sets per Month
- Qingdao Tianjin Shanghai Ningbo or as per demand
- T/T L/C D/P D/A Credit Card PayPal
- HYDZ-1 feeding ore granules powder electromagnetic vibrating feeder
- Ball mill plant used automatic feeding electromagnetic vibrating feeder
- seating types metallurgy granules electro magnetic vibrating feeder
- limestone production used mini magnetic vibrating feeder
- closed types cement powder conveying used magnetic vibrating feeder
- electro discharging material machine vibrating feeder
Product Details
Condition: | New | Application: | Ore, Coal Mining | Power Type: | Other |
Capacity(t/h): | 5T/H | Place of Origin: | Henan, China | Brand Name: | hongyuan |
Model Number: | GZ-1, pellet granules material charger magnetic vibrating feeder | Power(W): | 0.06 | Dimension(L*W*H): | 910*376*485 |
Weight: | 150Kg | Certification: | ISO,CE,CCC | Warranty: | 1 Year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
In standard fumigation plywooden box
Product Description
pellet granules material charger magnetic vibrating feeder is one kind of universally supporting feeding equipment. It is suitable for evenly feeding any kinds of powder, granules or blocks into the another receiving machine at rationed weight. It is the necessary machine for automatic prodcution line.
pellet granules material charger magnetic vibrating feeder is one complete double particle orientation forced vibration elastic system. The whole system is working under the low critical resonance state. Adopts the electromagnetic vibrator drive the feeder trough do the reciprocating vibration in certain angle and the whole system can make the material move as per the trough.
Hanging types vibrating feeder
Seating types vibrating feeder
Closed types vibrating feeder
Type | Model | capacity(t/h) | Granule size (mm) | Double amplitude (mm) | Voltage (V) | Elevtric Current (A) | Power (Kw) | Control cabinet | ||
horizontal | -10° | Running current | Indicates current | |||||||
Basic type | GZ1 | 5 | 7 | 50 | 1.75 | 220 | 1.34 | 1 | 0.06 | XKZ-5G2 |
GZ2 | 10 | 14 | 50 | 3.0 | 2.3 | 0.15 | ||||
GZ3 | 25 | 35 | 75 | 4.58 | 3.8 | 0.2 | ||||
GZ4 | 50 | 70 | 100 | 8.4 | 7 | 0.45 | XKZ-20G2 | |||
GZ5 | 100 | 140 | 150 | 12.7 | 10.6 | 0.65 | ||||
GZ6 | 150 | 210 | 200 | 1.5 | 380 | 16.4 | 13.3 | 1.2 | XKZ-20G3 | |
GZ7 | 250 | 350 | 250 | 24.6 | 20 | 3 | ||||
GZ8 | 400 | 560 | 300 | 39.4 | 32 | 4 | ||||
GZ9 | 600 | 840 | 350 | 47.6 | 38.6 | 5.5 | XKZ-200G3 | |||
GZ10 | 750 | 1050 | 500 | 39.4*2 | 32*2 | 4*2 | XKZS-200G3 | |||
GZ11 | 1000 | 1400 | 500 | 47.6*2 | 38.6*2 | 5.5*2 | ||||
Upper vibration type | GZ3S | 25 | 35 | 75 | 1.75 | 220 | 4.58 | 3.8 | 0.2 | XKZ-5G2 |
GZ4S | 50 | 70 | 100 | 8.4 | 7 | 0.45 | XKZ-20G2 | |||
GZ5S | 100 | 140 | 150 | 12.7 | 10.6 | 0.65 | ||||
GZ6S | 150 | 210 | 200 | 1.5 | 380 | 16.4 | 13.3 | 1.5 | XKZ-20G3 | |
GZ7S | 250 | 350 | 250 | 24.6 | 0 | 3 | XKZ-100G3 | |||
GZ8S | 400 | 560 | 300 | 39.4 | 32 | 4 | ||||
Closed type | GZ1F | 4 | 5.6 | 40 | 1.75 | 220 | 1.34 | 1 | 0.06 | XKZ-5G2 |
GZ2F | 8 | 11.2 | 40 | 3 | 2.3 | 0.15 | ||||
GZ3F | 20 | 28 | 60 | 4.58 | 3.8 | 0.2 | ||||
GZ4F | 40 | 56 | 60 | 8.4 | 7 | 0.45 | XKZ-20G2 | |||
GZ5F | 80 | 112 | 80 | 12.7 | 10.6 | 0.65 | ||||
GZ6F | 120 | 168 | 80 | 1.5 | 380 | 16.4 | 13.3 | 1.5 | XKZ-20G |
Model | B | B1 | B2 | B3 | B4 | L | L1 | L2 | L3 | H | H1 | H2 | H3 |
GZ1 | 200 | 280 | 340 | 296 | 376 | 600 | 209 | 550 | 910 | 100 | 350 | 360 | 485 |
GZ2 | 300 | 388 | 456 | 400 | 506 | 800 | 310 | 660 | 1171 | 120 | 430 | 450 | 600 |
GZ3 | 400 | 496 | 518 | 452 | 574 | 900 | 311 | 790 | 1325 | 150 | 480 | 520 | 675 |
GZ4 | 500 | 620 | 682 | 581 | 762 | 1100 | 413 | 965 | 1615 | 200 | 550 | 645 | 814 |
GZ5 | 700 | 761 | 850 | 650 | 840 | 1200 | 465 | 1050 | 1815 | 250 | 647 | 765 | 980 |
Model | B | B1 | B2 | B3 | B4 | L | L1 | L2 | L3 | L4 | H | H1 | H2 | H3 | H4 | R |
GZ6 | 900 | 1057 | 720 | 860 | 1092 | 1600 | 500 | 1360 | 2410 | 1409 | 250 | 1090 | 1030 | 1530 | 460 | 1800 |
GZ7 | 1100 | 1257 | 840 | 1030 | 1332 | 1800 | 650 | 1465 | 2800 | 1585 | 250 | 1300 | 1130 | 1740 | 500 | 2200 |
GZ8 | 1300 | 1476 | 1000 | 1166 | 1556 | 2200 | 750 | 1800 | 3302 | 1938 | 300 | 1460 | 1340 | 1695 | 607 | 2600 |
GZ9 | 1500 | 1676 | 1010 | 1228 | 1776 | 2400 | 800 | 2000 | 3515 | 2100 | 300 | 1520 | 1440 | 2200 | 660 | 3500 |
pellet granules material charger magnetic vibrating feeder
