Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved

Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-1
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-2
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-3
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-4
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-5
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved thumbnail-6
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-1
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-2
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-3
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-4
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-5
Factory Direct Sell Wood Sawdust Smokeless Charcoal Producing Kiln With ce Approved photo-6
US$ 7,865 - 18,692 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Air Flow
Application:
Making Charcoal Powder
Contact Supplier Request Quote Chat Now
Gongyi Xiaoyi Mingyang Machinery Plant
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Shanghai Ningbo and any ports in china
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Air Flow
Application Making Charcoal Powder
Place of Origin Henan, China
Brand Name Mingyang
Model Number THL
Effective Volume 2.9*4*5
Dimension(L*W*H) 4800*1800*3200mm
Weight 11.2T, 11.2-11.5t
Voltage 380V
Power(W) 7.22kw
Certification ISO CE, ISO&CE
Warranty 12 Months
After-sales Service Provided Engineers available to service machinery overseas

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

 smokeless charcoal producing kiln

The general intriduction of  smokeless charcoal producing kiln

The smokeless charcoal producing kiln with four charring tube equiped with the charring stove, raw materials will have 4-level charring process, the final product is totally carbonized.
Equipped with special cooling system, the final product almost no temperature, can put into next working process directly, will save the cooling time.
Newly developed purification system, makes no smoke durning the whole working process.

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

 Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approvedFactory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

Technology data of smokeless charcoal producing kiln:

  • power :7.22kw ( main machine: 5.5kw, fan 1.5kw+0.22kw)
  • capacity :150-180kg/h
  • Package dimension:4800*1800*3200mm
  • Net/Gross weight:11.2/11.5ton
  • temperature of inner stove:480-600 degree
  • Raw material requirement :sawdust, Size: 3-5mm, moisture:8-12%
  • energy consumption:35-40kg firewood per shift
  • Electricity consumption:7.22kw/h
  • motor style :5.5kw Moment speed regulating motor
  • Used for: Firecracker production, active carbon processing, certain soil improvements by scientific research unit.
  • Rotary speed :1450r/min

 Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

Working process of  smokeless charcoal producing kiln

Firstly,Using the wood sawdust carbonization stove sieved to screen sawdust with different size to eliminate bigger impurity.
Then drying the sieved sawdust if the moisture content is large than 8-12%, that is better carbonize for sawdust carbonization stove.
Finally, Putting the raw material into the wood sawdust carbonization stove to charring it. The sawdust will be carbonized four times.There are four tubes equiped with the stove.
Wood sawdust carbonization stove is fully automatic and continuous work.There have purification system,so it can protect the environment.

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved
The main structure of  smokeless charcoal producing kiln

This model machine consists of heating parts, carbonizing parts,  cooling parts,   gas recycle parts,

smoking purification parts, and controlling parts.

Heating parts

includes three heating room (for heating the stove), furnace body and heat

keeping layer (it is made of the heat insulating material, used for keep the

heating) and the drought fan

Carbonizing parts

consist of four carbonizing tubes, Both of them are made of the heat

resistance

 thermal steel, under the drive of the machine, the sawdust will be delivery

 to the

tube1, when the sawdust reach to the end of the tube1,it will turn around to the

tubes2, and so on,  after four tubes carbonization, the sawdust will become

charcoal powder.



Gas recycle parts

When during the process of carbonizing, there will be some smoke

(can be burning)

the smoke can return to the furnace through tube for purifying, after

purification ,

the gas recycle tubes can be flow into the heating room of the main furnace for

 heating the

machine again.

Smoking

purification parts

( in this machine, there are  two purification  tank, the first one to purify the

smoking ( can not burning ), and the other one are used to purification the

gas smoking when the working process, The smoking through the purification

 system.will

become water vapor, and it will not pollute the air.

Cooling parts

in the back side of the machine, there is one tube for cooling the hot

charcoal

 powder, so we can get the charcoal powder directly.

Controlling parts

the whole machine we will equip one electrical control box to control the

three electrical motors.

The advantages of  smokeless charcoal producing kiln

  • smokeless charcoal producing kiln is adopted international advanced technology  to increase the carbonization ratio from 80%to 99%,
  • This novel design product shows the features of high efficiency ,energy-saving,easy to operate and maintain ,low investment and high revenue,environment protection and so on.It is an ideal equipment to carbonize.
  • The smokeless charcoal producing kiln can working 24hours,and it will increase the output  of charcoal powder, it is popular in the European market.

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved



Packaging & Shipping

The packaging and shipping of smokeless charcoal producing kiln

 Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approvedFactory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

Our Services

  Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved





Buying Guides

1. Contact me first and make a deal;

2. Sign order and then pay the down payment;

3. Receive the down payment, we arrange our factory to produce the machines;

4. After finished the manufacturing, we test, examine the machines;

5. The last step is to transport the machines to your country port. The whole line is finished.



Company Information

Gongyi Xiaoyi Mingyang Machinery Plant
is located in Zhengzhou City, which is the biggest manufacturing base of charcoal making machinery. And we are the one of the earliest and largest manufacturers of renewable fuel & energy equipments and related machinery.

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approvedFactory direct sell wood sawdust smokeless charcoal producing kiln with ce approved.

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved

After 15 years development, now our company becomes an independent economic entity with the integration of science, engineering and trading department. our products and are widely accepted in both domestic and world market, and also exported to more than 30 countries, such as England, Russia, Sweden, Poland, Iran, Sudan, South Malaysia, Indonesia, Vietnam, etc

Factory direct sell wood sawdust smokeless charcoal producing kiln with ce approved
