Specifications
magnetic gold separator:1.Simple structure and easy to maintain
2.Short magnetic circuit
Gold separator Introduction:
Gold separator machine is designated for wet magnetic separating of material with granularity below 3mm, such as magnetite, magnetic pyrite, roasted ore and ilmenite. It can also be used to remove iron for coal, nonmetal materials, building materials, etc. Our Magnetic Separators are designed to recover ferromagnetic materials. The separators are available in designs and sizes to provide solutions for all applications.
Gold separator Features:
1. Simple structure and easy to maintain.
2. Short magnetic circuit.
3. Little magnetic flux leakage.
4. High magnetic intensity, low energy consumption.
5. Fine beneficiating results.
Gold separator Principle:
When the ore pulp folw into the magnetic field, the strong magnetic minerals are adsorbed on the surface of the drum. The weak magnetic and nonmagnetic minerals are cast off and discharged, while the strong magnetic minerals on the surface of the drum rotate with the drum and will be brought out of magnetic field to complete the sorting operation.
Parameter:
Model |
Magnetic intensity |
Capacity | Power |
Weight |
CTB600×1200 |
1450 |
8-15 |
1.5 |
910 |
CTB600×1800 |
1500 |
15-25 |
2.2 |
1340 |
CTB750×1800 |
1550 |
30-45 |
3 |
2050 |
CTB900×1800 |
1650 |
35-60 |
4 |
3000 |
CTB1050×2400 |
1650 |
60-95 |
5.5 |
5020 |
CTB1200×3000 |
1650 |
80-150 |
7.5 |
7800 |
CTB1500×3000 |
1650 |
120-200 |
11 |
9600 |
service concept:
1.Pre-sale services:
1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;
3) Training technical personnel for our clients;
4) Providing construction and technology consultations or working out proper construction schemes for those new, special or difficult projects.
2.Services provided during the sale:
Respect our clients; present the clients with ease, relaxation and a surprise; devote ourselves to improve the total value of our clients.
1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients.
3. After-sale services:
Improve the added value of our products, and let the clients free from the using troubles:
1) Assisting the clients preparing for the first construction scheme;
2) Installing and testing the equipments;
3) Training the first-line operators on site;
4) Examining the equipment regularly;
5) Taking the initiatives to eliminate the failure(s) rapidly at site;
6) Distributing the guarantee fittings door-to-door;
7) Providing technical exchanging;
8) Providing maintenance for big items.
For more information, Please to visit: /group/en-us/
