4x4 Compact Tractor With Loader, Wheeled Tractor DQ404 With Front End Loader and Backhoe Attachment

4x4 Compact Tractor With Loader, Wheeled Tractor DQ404 With Front End Loader and Backhoe Attachment thumbnail-1
4x4 Compact Tractor With Loader, Wheeled Tractor DQ404 With Front End Loader and Backhoe Attachment photo-1
US$ 1,900 - 7,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, Wheel Tractor, 4WD farm tractor
By wheel:
4WD
Contact Supplier Request Quote Chat Now
Gooler International Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao / Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, Wheel Tractor, 4WD farm tractor
By wheel 4WD
Usage Farm Tractor
Certificate EPA
Brand Name DQ brand
Model Number DQ404, TZ04D, LW-7
Place of Origin Shandong, China

Specifications

1.4in1 bucket
2.Quick linkage system
3.Triple linkage control
4.Teeth and mesh on bucket
5.Pallet fork, timber grapple



Front end loader specifications fit with 25HP to 160HP tractors











-Standard level lift.







-Perfect painting and finishing in details.







-Special requests on the the size of bucket are available







-Quick release bracket and it is very easy for installation.







-Quick release attachment which can work with others Extensive implements







-4 in 1 bucket, pallet fork and wood Grapple are available on it.











-Adopt Germany technical and with CE certificate











Front end loader Main Characters Summary











-Used in Shoveling, stacking or short-distance transportation of loose material like mud, sand, stone or garbage.







-Featured with compact structure, flexibility, convenient operation and quick mounting and dismounting. It used hydraulic oil commonly with tractor. The hydraulic elements are standardized, convenient for operation and service.



-Different work devices are optional, such as combined buckets, grating cover bucket, pallet handler, timber grab and bale fork, etc, so as to accomplish different kinds of work successfully.







Model

TZ03D

TZ04D

TZ06D

TZ08D

Tractor model

254/284/304/354

404/454/504/554

604/654/704

754/804/854/904

Height-measured at arm pivot point (mm)

2700

2800

3100

3080

Max. dump height (mm)

2000

2100

2300

2350

Dump distance (Max. dump height) (mm)

800

900

1100

1100

Dump angle (°) (Max. dump height) (mm)

45

45

45

43

Distance to the centre of front-wheel (mm)

1900

1900

2300

2400

Rollback angle on ground (°)

32

32

34

34

Max. digging depth (mm)

140

140

140

180

Bucket width (mm)

1400

1500

1600

1700

Bucket capacity (m3)

0.21

0.23

0.43

0.46

Rated lift capacity (Kg)

350

600

700













































4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment

4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment4x4 compact tractor with loader, wheeled tractor DQ404 with Front end loader and Backhoe attachment
