Home > Products > WATER PUMP > Gasoline Engine Driven Water Pump (Max.Flow Rate 21m3/h)
Gasoline Engine Driven Water Pump (Max.Flow Rate 21m3/h)
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai China
- T/T
You May Like
-
5.5HP Gasoline Engine water pump (Max.Flow Rate 21m3/h)
-
5.5HP Gasoline Engine Water Pump (Max.Flow Rate 20m3/h)
-
2.5HP Gasoline Engine Water Pump (Max.Flow Rate 21m3/h)
-
7.2HP Diesel Engine Driven Water Pump
-
Diesel Engine Driven Water Pump(Max.Flow Rate 14m3/h)
-
Diesel Water Pump WP20D(E)/40D(E) Displacement 30/85 m3/h
Product Details
| Place of Origin | Jiangsu, China | Brand Name | JDP | |
| Model Number | WP15B | Structure | Other, impeller pump | |
| Usage | Water | Power | Other, gasoline engine | |
| Standard or Nonstandard | Standard | Fuel | Gasoline | |
| Pressure | High Pressure |
Product Description
Specifications
1) Heavy-duty full frame protection2) For construction, agriculture using.
| Model | WP-15B |
| Outlet Size(mm) | 40 |
| Inlet Size(mm) | 40 |
| Speed(rpm) | 3600 |
| DisplacementQ.max(m3/h) | 21 |
| Lift H.max(m) | 20 |
| Suction(m) | 7 |
| Engine Model | G152 |
| Max Output(kw)/HP | 2.5 |
| Engine Type | Forced air-cooled 4-stroke valve-sided |
| Bore*Stroke(mm*mm) | 52mm×46mm |
| Displacement | 97.1ml |
| Compression Ratio | 5.6:1 |
| Max Power Output | 1.8kw/4200rmp |
| Recommend Power Using | 1.6kw/3600rmp |
| Max Torque | 3.8N.m/3000rmp |
| Start Model | Recoil and hand operated |
| Lgnition System | tranafstorilzed magneto |
| Air Cleaner | seml-dry type |
| Fuel Tank Capacity | 1:4L |
| Fuel Cinsumption | ≤450g/kw.h |
| Package Dimensions(mm) | 410×290×410 |
| N.W/G.W(kg) | 12.0/13.0 |
