CE Certificate Crawler Excavator 45-7B

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

CT45-7B

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name CT

Model Number CT45-7B

Condition New

Moving Type Crawler Excavator

Operating Weight 4200KG

Bucket capacity 0.17CBM

Maximum Digging Height 5030mm

Maximum Digging Depth 3405mm

Max Digging Radius 5530

Rated Speed 4.4/2.7km/h

Certification CE

After-sales Service Provided No overseas service provided

Specifications

1.crawler excavator 45-7B
2.engine:Japan Yanmar 4TNV88(25.2KW/2200RPM)
3.rated power:25.2KW
4.bucket capacity:0.17cbm

Specifications:

Excavator model			MAP 45-7B with cab


Cargo body size (LxWxH) (mm), 20GP:569021302180			load 2 units in one 40 HQ container
Operate weight kg			4200 kg
Bucket capacity M3			0.17m³
Engine model			Yanmar 4TNV88
Engine power (kw)			25.2 Kw
Swing speed (rpm)			11 rpm
Ground pressure (KPa)			38.7
Travel speed (km/h)			4.4/2.7
Tracking force (kn)			34.1
Gradeability (°)			30°(58%)
Main dimensions	Upperstrcuture witdth (mm)		1600
	Undercarriage width (mm)		1750
	Cabinet height (mm)		2455
	Rear swing radius (mm)		1600
	Ground clearance (mm)		350
Working range		Max.digging radius (mm)	5530
		Max.digging depth (mm)	3405
		Max.digging height (mm)	5030
		Max.dumping height (mm)	3410
		Max.dozer cutting depth (mm)	380
		Max.dozer lifting height (mm)	255
Standard Equipment		Japan made KYB main pump
		Japan made KYB travel motor
		Japan made KYB swing motor
		Japan KYB multi-circuit valve ,pilot control lever Japan KYB
		Japanese Bridgestone rubber track
		Cold & warm air conditioner supply under different kinds of weather conditions
