HY610 CE Certificate Crawler Excavator

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

HY610

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name FM

Model Number HY610

Condition New

Moving Type Crawler Excavator

Operating Weight 2500KG

Bucket capacity 0.5CBM

Maximum Digging Height 2650MM

Max Digging Radius 360

Certification CE

Specifications

1.crawler excavator HY610
2.engine:Yanmar engine B3.3
3.rated power:25.2KW/24.6KW/35.7KW
4.bucket capacity:0.5CBM

SPECIFICATION:

HY610
Engine Model	Yanmar(4TNV-88-SYY/Perkins404D-15/Perkins404D-22)
Engine type	In-line arrangement, water-cooled,four-cycle diesel
Rated power	25.2KW/24.6KW/35.7KW
Rated speed	2200rpm
Transmission system
Type	Fixed-spindle power shift
Shift gear control oil pressure	1.2-1.5MPa
Rated input speed	2500(rpm)
Bucket
Bucket capacity	0.5m3
Bucket width	1550mm
Bucket type	heavy-duty bolt on teeth
Max.Breakout Force	32KN
Rated load	1000kg
Operating weight	2500kg
Overall Dimensions
Overall Length(Bucket on ground position)	4530mm
Overall Height
Ground to Cab Top	2500mm
Min.Base to the ground	240mm
Dumping height	2650mm
Overall Width	1500mm
Operating Specifications
Steering system	Articulated Frame with hydraulic power steering
Min.Turning Radius	4400mm
Driving system	Hydraulic Converter
Brake system
Service Brake	Four wheel Hydraulic spread-shoed brake
Parking brake	hand-operated
Tyre
Model	12-16.5
Wheel base	1750mm
Track	1200mm
Minimum Order Quantity	1-99
Packaging details	Nude package,3Units/40's HQ
Payment Details	Payment Terms T/T, L/C
FOB Port	Qingdao, China
Delivery time	15 to 21days after confirm the order
