Chinese 6ton Crawler Excavator With CE,cummins Engine

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

CT60-7A

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name FM

Model Number CT60-7A

Condition New

Moving Type Crawler Excavator

Operating Weight 5830KG

Bucket capacity 0.20CBM

Maximum Digging Height 6100mm

Maximum Digging Depth 3875mm

Machine Weight 5830KG

Max Digging Radius 360

Rated Speed 4.0/2.5km/h

Certification CE certificate

After-sales Service Provided No overseas service provided

Specifications

1.crawler excavator CT60-7A
2.engine:Cummins engine B3.3
3.rated power:45KW
4.bucket capacity:0.20CBM

SPECIFICATION: 6ton crawler excavator with cummins engine,CE

Engine Model	Cummins engine B3.3 45KW/2200rpm
WEIGHT:
Operating weight:	5830KG
CAPACITY:
Bucket capacity:	0.20m3
DIMENSIONS:
Undercarriage Width	1880 mm
Center clearance between tracks	1480 mm
Dozer height	400 mm
Dozer width	1880 mm
Dozer lifting height	300 mm
Dozer cutting depth	595 mm
Rear swing radius	1700 mm
overall length for transportation	6070 mm
Overall height	2650 mm
Clearance under upper structure	780 mm
Track width	400 mm
Max digging height	5785mm
Max. digging radius	6245 mm
Max. digging depth	3875mm
Max. dumping height	4095 mm
Max digging radius on the ground	6100 mm
HYDRAULIC SYSTEM:
Main pump	Germany Rexroth gear pump;
Flow /pressure:	42.2L/min 2200rpm/24.5Mpa
Working attachments:	Boom/Arm/Bucket
Overload pressure:	24.5MPa
PARAMETERS:
Swing speed:	10RPM
Ground pressure:	34KPa
Travel speed:	4.0/2.5km/h
Tracking force:	49.3KN
Gradeability:	30(58%)
Bucket digging force:	36.7KN
Arm digging force:	26.1KN
