Help CenterCT45 Crawler Excavator for Sale
Related Products
-
4.5Ton CE Approved Crawl ExcavatorNegotiableMOQ: 1 Unit -
CE Certification Mini 4.5 Tons Crawler Excavator With 0.17m3 Bucket CT45-7ANegotiableMOQ: 1 Unit
-
24ton Excavator CT240-7A CE Certificate,construction MachineNegotiableMOQ: 1 Unit
-
CT240-7A CE Certificate Excavator,construction MachineNegotiableMOQ: 1 Unit
-
Cheap Crawler Excavator CT45-7B, Construction Machine,4.5ton ExcavatorNegotiableMOQ: 1 Unit
ENGINE | |
Engine Model |
YANMAR 4TNV88 |
Engine power |
27KW |
WEIGHT: | |
Operating weight: |
4200KG |
CAPACITY | |
Bucket capacity: |
0.17m3 |
DIMENSIONS | |
Upperstructure width (mm) |
1600 |
Undercarriage width (mm) |
1750 |
Cabinet height (mm) |
2455 |
Rear swing radius (mm) |
1600 |
Ground clearance (mm) |
350 |
Clearance under counter weight(mm) |
585 |
Tumbler distance(mm) |
1710 |
Overall length for transportation(mm) |
5500 |
Max. digging radius at ground level(mm) |
5420 |
Max vertical digging depth(mm) |
2900 |
Max. digging radius (mm) |
5530 |
Max. digging depth (mm) |
3405 |
Max. digging height (mm) |
5030 |
Max. dumping height (mm) |
3410 |
Max. dozer cutting depth (mm) |
380 |
Max. dozer lifting height (mm) |
255 |
HYDRAULIC SYSTEM | |
Main pump |
Japan made KYB main pump |
Flow /pressure: |
10.8L/min 2200RPM/4.9MPA |
Working attachments: |
Boom/Arm/Bucket |
Overload pressure: |
24.5MPa |
PARAMETERS | |
Swing speed: |
11RPM |
Travel speed: |
4.4/2.7km/h |
Tracking force: |
34.1KN |
Gradeability: |
30(58%) |
Bucket digging force: |
23.7KN |
Arm digging force: |
20.4KN |
Rubber/Steel tracks: Bridgestone Travel motor
The standard rubber track lets you work on multiple Imported Japan made KYB Travel motor.
surfaces such as grass, pavement or stone without
damaging the surface or machine.
Full open engine cover: YANMAR engine
The full open engine cover can be fully opened and is Imported YANMAR 4TNV88 27KW/2200rpm engine
easy for maintenance.
Main pump Simple Dozer Control with Float Function
Imported Japan made KYB Main pump
Digital monitor Swing cylinder
Gives the operator full function display with on-line
inspection.
