Hot Sale YTO Crawler Bulldozer YD230

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

Model Number:

YD230

Weifang Fumei Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO CHINA

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name FM

Model Number YD230

Condition New

Moving Type Crawler Bulldozer

Machine Weight 24200KG

Dimension(Long * Breadth * High) 6830x3725x3522mm

Specifications

1.Crawler bulldozer YD230
2.engine:NTAA855-C280S20
3.rated power:179kw
4.dimension:6830x3725x3522mm

YD230 Hydraulic Track Bulldozer

Main features

1. And 2 emissions by countries engine, energy conservation and environmental protection.

2. Using the American Donaldson air filter and postfilter device, prolong engine life, increase maintenance interval.

3. Engine muffler cancel ejector device, increase exhaust given it, reduce the exhaust pressure, and then reduce the fuel consumption.

4. Adopt sealed measures before and after heat isolation cooler air, which improves the cooler to come loose hot effect.

5. Hydraulic filter increase alarm device, timely remind users cleaning cartridge or replace hydraulic oil.

6. Air conditioner cooler decorate in hood is below, can use the engine cooling air cooling, increase the cooling effect.

7. Oil, water and other daily maintenance point humanized decorate, inspection, maintenance is convenient.

8. Earth-moving oil cylinder lead high buy, reduce oil cylinder and former head of stress, and convenient check and repair engine.

Technical Specifications

Model		YD230
Total weight	KG	24200
Max. towing force	KN	266
Engine model		NTAA855-C280S20
Engine rated power	KW	179
Engine rated speed	r/min	2000
Forward travel speed	Km/h	Forward Ⅲ gear3.8-11
Reverse travel speed	Km/h	Reverse Ⅲ gear4.9-13.6
Track board width	mm	560
Land pressure	K pa	76
Overall dimension(Lx W x H)	mm	6830x3725x3522
Bulldozer shovel(W x H)	mm	3725x1395
Max. lifting height of bulldozer	mm	1210
