HY series linear vibrating classifier has a long history in designing and manufacturing, which can be customized for clients, regardless of width, length, height, materials. Should you be interested in any items, please do not hesitate to contact us !
Features of the mining screen:
1. It can be continuous working, single or multi-layer auto-classification filtering.
2. Good sealing performance, no dust overflow.
3. Low consuming, high output.
4. Having no blockage in the screen, easily to change the screen.
5. It is easy to install,operate and maintain.
6. High utilization rate of screen, large unit area.
7. High-precision screening, large processing capacity.
Operating Principle of the mining screen:
Our series linear vibrating classifier is composed of a screen box, screen frame, vibration motor, damping system and mountings and other components. It is the vibration motor as vibration source, so that materials in the screen to be tossed, and at the same time, move forward in a straight line on the screen, then the materials from the feeder are discharged from their respective export separately.
Application of the linear vibrating classifier:
Linear vibrating classifieris suitable to sieving and grading powder or granule, widely used in many industries, such as ceramic, food, pharmaceutical, plastic, grinding, mining, chemical, medicine, building material, and fertilizer industries. Vibratory screens can be provided with dust proof cover as required. Vibrating screen can be supplied of different sizes depending upon capacity required. They can also handle slightly wet material.
Technical parameters of the vibrating classifier:
Model |
HY-520 |
HY-525 |
HY-1020 |
HY-1025 |
HY-1030 |
Appearance Dimension |
500×2000 |
500×2500 |
1000×2000 |
1000×2500 |
1000×3000 |
Material Granularity |
0.074-10 |
0.074-10 |
0.074-10 |
0.074-10 |
0.074-10 |
Angle |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
1°-7° |
Amplitude(mm) |
3-4.5 |
3-4.5 |
3-4.5 |
3-4.5 |
3-4.5 |
Layer |
1-6 |
1-6 |
1-6 |
1-6 |
1-6 |
Power(KW) |
2× (0.37-0.75) |
2×(0.37-0.75) |
2× (0.55-1.1) |
2× (0.55-1.1) |
2× (0.55-1.1) |
Some pictures of the linear vibrating classifier parts
Rubber balls
Sieve frame
Vibrating motor
We can offer the best machine and service for you , please contact us now !
Our CE certification
If you need more information, contact me now!
Accept special customization.
