Mineral Vibrating Feeder/feeding Machine

Mineral Vibrating Feeder/feeding Machine thumbnail-1
Mineral Vibrating Feeder/feeding Machine photo-1
US$ 800 - 6,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Mineral Vibrating feeder, Powder, granule
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Xinxiang Hengyu Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao or request
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Mineral Vibrating feeder, Powder, granule
Power Type Electric
Capacity(t/h) customized
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number ZG
Power(W) depend on the model
Dimension(L*W*H) depend on the model
Weight depend on the model
Certification ISO9001:2008, CE
Warranty 1 years
After-sales Service Provided Engineers available to service machinery overseas

   mineral vibrating feeder/feeding machine



---------------------------------------Introduction--------------------------------------------------



mineral vibrating feeder is a kind of general feeding device, which tends to standardization. It is widely applicable for relevant industries to convey all kinds of block, particle and dust materials in short distance. The feeder can well implement the on-line and automatic operation with continuous conveying system like belt, automatic scaling and quantitative packing system etc. It is an ideal feeding and conveying device for the industries of metallurgy, mining, coal, construction material, chemical, power, and grain process.







-------------------------------------------Features--------------------------------------------------



* Simple structure, light weight, low noise, reliable work, feeding capacity, easy installation and maintenance

*Overhead suspended spring suspension

* Excellent service life of the electromechanical motors with little maintenance

* Easy maintenance and low operating cost

* Simple structure, light weight, low noise, reliable work, feeding capacity, easy installation and maintenance





----------------------------------Technical parameters-------------------------------------------



Model

Feed size(mm)

Capacity

(t/h)

Motor

Power

(KW)

Double amplitude

Weight(KG)

Close

Open

ZG-25

60

25

YZS-2.5-4

0.25*2

2-3

240

174

ZG-30

80

30

YZS-5-4

0.4*2

2-3

256

184

ZG-50

90

50

YZS-5-4

0.4*2

2-3

295

235

ZG-100

105

100

YZS-8-4

0.75*2

2-5

384

321

ZG-200

115

200

YZS-17-4

0.75*2

2-5

432

372

ZG-400

140

400

YZS-20-4

2.0*2

2-5

686

606

ZG-750

190

750

YZS-30-4

2.5*2

4-6

1258

1030

ZG-1000

215

1000

YZS-50-4

3.7*2

4-6

1446

1156





-------------------------------------------Functions---------------------------------------------------



This equipment is used to feed block or granule materials from material storage to a charging device evenly and continuously. Used to achieve an even feeding for crushers in sandstone production lines, and to make a rough screening of materials, this equipment is widely used in combined operation with crushing and screening machines in a range of industries.





-----------------------------------Maintenance and operation-----------------------------------



1. Before you use the machine, test whether the machine is normal operation, please.
2. If it has any abnormal phenomenon, maintenance in time.
3. After using, clean equipment.
Notes:
1. According to clients’ needs, our company can design and manufacture vibrating feeder of special type and specification.
2. Our company has reserve the right to adjust all technical information and size.
3. When ordering, please indicate the specifications, material name, processing capacity, conveying distance and other parameters.







----------------------------------------Choose the right model------------------------------------



There are some considerations to keep in mind when choosing the right feeding system.
1. Different manufacturers have added various innovations to their equipment, such as an option to limit vibration noise by frequency control.
2. Check that the vibrating feeder that you select is suited to your industry and intention. Also the materials that the feeder will be processing should be considered.
3. Customer Sales Representatives can provide excellent advice and information to help you make an informed idea. Choose a Sales Rep that you feel comfortable with and provide him with a clear idea of your intention for the feeder.





---------------------------------------The similar type model ------------------------------------

Mineral Vibrating feeder/feeding machine

Mineral Vibrating feeder/feeding machine





-----------------------------------------------Contact us--------------------------------------------



We are ready for you, please contact us,the good mineral vibrating feeder can be given!
