Hengyu Brand Vibrating Feeder for Adjustable Speed

Hengyu Brand Vibrating Feeder for Adjustable Speed thumbnail-1
Hengyu Brand Vibrating Feeder for Adjustable Speed photo-1
US$ 859 - 6,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Cement,coal, building industry and other departments...
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Xinxiang Hengyu Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Cement,coal, building industry and other departments...
Power Type Electric
Capacity(t/h) 15t/h
Place of Origin Henan, China
Brand Name HENG SHUN
Model Number vibrating feeder - 100
Power(W) 7.4kw
Dimension(L*W*H) As per the model you choose
Weight 0.75*2 kw
Certification ISO9001:2008, CE
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Vibrating feeder for adjustable speed
1.Stainless or Carbon Construction
2.Smooth Conveyance Action
3.Reliable operation



Hengyu brand vibrating feeder for adjustable speed

Summary Description

Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed use of self-synchronization principle of two eccentric vibration motor, and form a horizontal 60 ° angle of the resultant  force, through periodic vibration, thus promoting the throw or gliding to the materials within the trough reached the granular, small block and powdered materials from storage silos  to the subject material equipment in uniform, quantitative, continuously.

Features of vibrating feeder for adjustable speed Hengyu brand vibrating feeder for adjustable speed

1. Vibrating motor as excitation source.

2. Stable vibration, reliable operation and long service life.

3. Convenient to adjust transferring capacity.

4. Overhead suspended spring suspension.

5. Characterized by even feeding, excellent continuity and adjustable vibrating force.

6. Material according to parabolic trajectory continuous forward for jumping movement, so feed groove wear smaller.

Technical parameters

Hengyu brand vibrating feeder for adjustable speed

Model

Feed size(mm)

Capacity

(t/h)

Motor

Power

(KW)

Double amplitude

Weight(KG)

Close

Open

ZG-25

60

25

YZS-2.5-4

0.25*2

2-3

240

174

ZG-30

80

30

YZS-5-4

0.4*2

2-3

256

184

ZG-50

90

50

YZS-5-4

0.4*2

2-3

295

235

ZG-100

105

100

YZS-8-4

0.75*2

2-5

384

321

ZG-200

115

200

YZS-17-4

0.75*2

2-5

432

372

ZG-400

140

400

YZS-20-4

2.0*2

2-5

686

606

ZG-750

190

750

YZS-30-4

2.5*2

4-6

1258

1030

ZG-1000

215

1000

YZS-50-4

3.7*2

4-6

1446

1156



Structure of vibrating feeder for adjustable speedHengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed

Main applicable range

Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed is a kind of linear direction feeding equipment,which is widely used in mining, building-material, silicate and chemical industry in the crushing and screening plants,such as metallurgical industry, coal mining industry, mining-selecting, building, chemical and grinding industry, etc.

Hengyu brand vibrating feeder for adjustable speed

Picures of similar type vibrating feeder for adjustable speed Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed

Our best service

Hengyu brand vibrating feeder for adjustable speed

Hengyu brand vibrating feeder for adjustable speed

How to choose reliable operation vibrating feeder for adjustable speed suitable for you:

1. How about the capacity? Such as 5t/h,10t/h,20t/h etc.

2. What’s the max size of materials? Such as 5mm, 20mm, 50 mm, 100mm etc.

3. What’s material? Such as coal, powder, grain etc.

Tell me those data, we can help you choose the suitable machine for you.

Believe in us, best quality of vibrating feeder for adjustable speed will be offered to you; here please send us your e-mails now.

Hengyu brand vibrating feeder for adjustable speed
