Good Sealing Performance Durable Ore Feeder

Good Sealing Performance Durable Ore Feeder thumbnail-1
Good Sealing Performance Durable Ore Feeder photo-1
US$ 1,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
sand, solid, powder
Power Type:
Other, vibrating motor
Contact Supplier Request Quote Chat Now
Xinxiang Hengyu Machinery Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application sand, solid, powder
Power Type Other, vibrating motor
Capacity(t/h) 5-1000t/h
Place of Origin Henan, China
Brand Name HENG YU
Model Number ZG-25
Power(W) 0.75*2kw
Dimension(L*W*H) 900X512X400mm
Weight 240kg
Certification ISO9001:2008
Warranty 12 month
After-sales Service Provided Engineers available to service machinery overseas

Specifications

durable ore feeder
1.High efficiency transport
2.Easy to adjust & maintenance
3.Smooth conveyance action
4.Low noise

   Good Sealing Performance Durable Ore Feeder



-------------------------------------------------     Product's information     -------------------------------------------------



Hengyu durable ore feeder is a kind of general feeding device, which tends to standardization. It is widely applicable for relevant industries to convey all kinds of block, particle and dust materials in short distance.



Features of the model

1. Two electromechanical motors are used to generate linear motion.

2. Characterized by even feeding, excellent continuity and adjustable vibrating force.

3. Material according to parabolic trajectory continuous forward for jumping movement, so feed groove wear smaller.

4.  Easy to operate and change or control the flow at any time;

5. Excellent service life of the electromechanical motors with little maintenance.

6. Low noise, will help to improve the working environment.



Product's Structure

good sealing performance durable ore feeder



Technical information

Model

Max granular
size(mm)

capacity
(t/h)

motor model

power (KW)

shaker
frequency
(r/m)

Double
amplitude
(mm)

exciting
force
(KN)

ZG-25

60

25

YZS-2.5-4

0.25×2

1500

2~3

5

ZG-30

60

30

YZS-2.5-4

0.25×2

1500

2~3

5

ZG-60

90

60

YZS-5-4

0.4×2

1500

2~4

10

ZG-80

160

80

YZS-5-4

0.4×2

1500

2~4

10

ZG-100

210

100

YZS-8-4

0.75×2

1500

2~5

16

ZG-200

270

200

YZS-8-4

0.75×2

1500

2~5

16

ZG-300

300

300

YZS-17-4

0.75×2

1500

2~5

34

ZG-400

300

400

YZS-17-4

0.75×2

1500

3~5

34

ZG-500

300

500

YZS-17-4

0.75×2

1500

3~5

34

ZG-750

400

750

YZS-30-6

2.5×2

1000

4~6

60

ZG-1200

400

1200

YZS-30-6

2.5×2

1000

4~6

60

ZG-1800

420

1800

YZS-75-6

5.5×2

1000

5~8

150

ZG-2000

420

2000

YZS-75-6

5.5×2

1000

5~8

150



See the pictures of ore vibrating feeder



good sealing performance durable ore feeder

good sealing performance durable ore feeder

good sealing performance durable ore feeder





Application

They are used where material is to be fed either continuously or in batches for
•Discharging bulk material from bins
•Feeding crushers, mixers, furnaces and scales
•Feeding conveyor belts, bucket elevators, vibratory screens, loading and sorting plants.
•Compared with other conveying means Vibrating Feeders have low energy consumption and cause little pollution. They are wear resistant and thus do not influence the quality and character of the product they handle.

good sealing performance durable ore feeder



















































































---------------------------------------------      Company's information       -------------------------------------------------



4 years Gold supplier certificated, 9 years in manufacturing experience.



Quality assurance

good sealing performance durable ore feeder

Quality assurance is the process of verifying or determining whether products or services meet or exceed customer expectations. We use the following methods to ensure the quality of our products:
a.Experienced staff
b.Quality control department
c.Third-party supervision

d.CE & ISO9001:2008 certificate

good sealing performance durable ore feeder



All of our order will be supplied within the stipulated period; we are here waiting for your inquiries!
