Specifications
Chinaware Mill:1. For cement, silicate, gypsum, limestone etc.
2. Wet or dry ball mill;
2013 Chinaware Mill
Introduction of Chinaware Mill
Ceramic ball mill mainly use for material mixing, grinding, size uniforming, energy saving. Dry grinding and wet grinding, different liner plate to satisfy with all demands. Size of final proudcts is controllable by grinding time. Soft-start motor reduces breakaway start current.
Small investment, energy saving, easy & safe operating,stable property are features of ceramic ball mill. It can be used for grinding or mixing common and special materials.According to material proportion, hardness, capacity and other reasons, there are different models ceramic ball mill, liner plate, medium for optional. [ball load: 0.05-15t/batch, motor power: 2.2-75kw]
Performance Feature of of Chinaware Mill
Ball mill mainly contains feeding part, discharging part, rotation part, transmission part(reducer, drive gear, motor, contrl system.) steel casting hollow shaft, exchangeable lining, gear hobbing rack wheel, wear-resisting liner plate make sure ball mill work steady and reliable.
Motor drives cylinder rotating by reduction gear. Frictional force and centrifugal force bring aterial and steel ball inside ball mill to a level, then drop down by gravity. The material being grinded and discharged eventually. The material goes through spiral classifier for getting acceptable products, and coarse product goes back to ball mill for re-grinding. The material being fed inside ball mill uniformly by combined feeder, and the ball mill can continuous working 24hours every day.
Technical Parameter of Chinaware Mill
Model |
Ball load(t/batch) |
Rotate speed(r/min) |
Motor power(kw) |
Liner plate material |
600×700 |
0.05 |
50 |
2.2 |
ceramic,silica,rubber,metal(motor diference exist according to different material) |
800×600 |
0.075 |
42 |
3 |
|
900×1200 |
0.2 |
38.5 |
5.5 |
|
1300×1500 |
0.5 |
33 |
7.5 |
|
1500×1800 |
1.2 |
28.5 |
11 |
|
1800×2000 |
1.5 |
24 |
15 |
|
2600×2800 |
5 |
16.5 |
37 |
|
3000×3800 |
10 |
14.5 |
57.2 |
