Product Details
| Condition: | New | Type: | Rotary Drilling Rig | Power Type: | Diesel |
| Place of Origin: | Henan, China | Brand Name: | Unique | Model Number: | KY125 |
| Usage: | Ore | Voltage: | 380V, 50HZ | Power(W): | / |
| Dimension(L*W*H): | 4000X2270X2050mm | Weight: | 3.3 | Certification: | ISO |
| Warranty: | More than 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High Performance Crawler Drill Rig with Cheapest Price
If you want to receive the price, please leave a message below, and I will send you the price within 24 hours.
Features of Crawler Drill Rig
1. This Crawler Drill Rig has low gravity center and big ground clearance, and can easily travel on bumpy road. It is driven by special wheel motor. That brings it strong grade-ability and low failure rate.
2. Equipped with advanced auto-balance and brake system, makes the crawler drilling rig travel stably and also greatly reduce its impact force to ensure the drive safety.
3. Special anti-lock device greatly
4. Adopt famous 4-cylinder diesel engine as driving force which has advantages of large power, small volume, small vibration and reliable operation.
5. Adopt patent diesel engine air inlet regulating device (Patent No. : 200820087606.3) and desert air filter three-stage filter. That strengthens the crawler drilling rigl’s adaptability to severe environment and lengthened the diesel engine’s service life.
Specification of Crawler Drill Rig
Specification | KY140 | KY130 | KY125 | KY120 | KY100 |
Rock hardness | F=6-20 | F=6-20 | F=6-20 | F=6-20 | F=6-20 |
Hole diameter (mm) | 105-140 | 105-140 | 80-115 | 105-120 | 80-105 |
Drill depth (m) | 25 | 25 | 25 | 25 | 20 |
Pressure (Mpa) | 1.0-2.4 | 1.0-2.4 | 0.7-1.4 | 1.0-1.4 | 0.5-0.7 |
Air consumption (M3/min) | ≥15 | ≥15 | ≥13 | ≥13 | ≥12 |
Rotating speed (Km/h) | 0-63 | 0-70 | 0-65 | 0-65 | 0-65 |
Lifting capacity (KN) | 20 | 18 | 17 | 17 | 15 |
Drill rod specification (mm) | 76×3000 /89×3000 | 76×3000 /89×3000 | 64×3000 /76×3000 | 64×3000 /76×3000 | 60×2000 |
Gradeability | 30° | 30° | 30° | 30° | 30° |
Ground clearance (mm) | 320 | 320 | 290 | 254 | 254 |
Walking speed (km/h) | 2.0 | 2.0 | 2.0 | 2.0 | 2.0 |
Drill arm rising angles (°) | -15~+50 | -15~+50 | -25~+50 | -35~+60 | -35~+60 |
Drill arm swing angle (°) | ±45 | ±45 | ±45 | - | - |
Carriage swing angle(°) | ±50 | ±50 | -45~+100 | -11.5~+36.5 | -11.5~36.5 |
Carriage pitch angle (°) | 180 | 180 | -50~+135 | -118.5~+23.5 | -118.5~+23.5 |
Carriage Compensation (mm) | 1200 | 1200 | 900 | 900 | 900 |
Overall Dimension (L*W*H)(mm) | 5850×2250 ×2020 | 5600×2340 ×2550 | 4000×2270 ×2050 | 5100×2030 ×2020 | 4100×2030 ×2020 |
Total Weight (Kg) | 5500 | 5500 | 3300 | 3300 | 3200 |
Note: | Pneumatic -hydraulic | Pneumatic -hydraulic | Pneumatic -hydraulic | Pneumatic -hydraulic | Pneumatic -hydrauli |
