Help CenterMolten Salt Pump
Related Products
In China, we are a leading manufacturer and supplier of molten salt pumps. According to the speed of molten salt pump can be divided into low-speed, medium speed, and high-speed molten salt pump. For example: In the 1450r / min speed of the molten salt pump, flow rate is above than 3 cubic meters / hour, head is above than 3m and the depth of the liquid is above than o.6m. We produce the molten salt pump Of the applicable temperature up to 600 ℃ operating temperature. In the low-speed, medium-speed and high-speed molten salt pump, their outlet diameter (DN) and efficiency are different, we can choose the most suitable model according to your requirements, if you want to know more pump information can be We contact, we have the ability to provide you with the best quality technical support and services.
Temperature (T): 180 ℃ ~ 540 ℃
Capacity (Q): 3 ~ 600 m3 / h
Head (H): 10 ~ 70 m
dielectric viscosity：μ＜300cp
Model |
Pump rated speed n =1450（r/min） |
||||
Capacity Q（m3/h） |
Head H（m） |
Efficiency η（%） |
Power of motor P（Kw） |
Length L （m） |
|
GY32-125 |
6.3 |
5 |
45 |
1.1 |
0.8～3.0 |
GY32-160 |
6.3 |
8 |
40 |
1.5 |
0.8～3.0 |
GY32-200 |
6.3 |
12.5 |
33 |
2.2 |
0.8～3.0 |
GY32-250 |
6.3 |
20 |
27 |
4 |
0.8～3.0 |
GY50-125 |
12.5 |
5 |
55 |
1.5 |
0.8～3.0 |
GY50-160 |
12.5 |
8 |
51 |
1.5 |
0.8～3.0 |
GY40-200 |
12.5 |
12.5 |
46 |
3 |
0.8～3.0 |
GY40-250 |
12.5 |
20 |
39 |
5.5 |
0.8～4.0 |
GY40-315 |
12.5 |
32 |
33 |
11 |
0.8～4.0 |
GY65-125 |
25 |
5 |
64 |
1.5 |
0.8～3.0 |
GY65-160 |
25 |
8 |
62 |
3 |
0.8～3.0 |
GY50-200 |
25 |
12.5 |
57 |
4 |
0.8～3.0 |
GY50-250 |
25 |
20 |
50 |
7.5 |
0.8～4.0 |
GY50-315 |
25 |
32 |
48 |
15 |
0.8～5.0 |
GY80-125 |
50 |
5 |
69 |
3 |
0.8～3.0 |
GY80-160 |
50 |
8 |
68 |
4 |
0.8～3.0 |
GY65-200 |
50 |
12.5 |
68 |
5.5 |
0.8～4.0 |
GY65-250 |
50 |
20 |
63 |
11 |
0.8～5.0 |
GY65-315 |
50 |
32 |
58 |
18.5 |
0.8～5.0 |
GY100-200 |
100 |
12.5 |
73 |
15 |
0.8～5.0 |
GY100-250 |
100 |
20 |
72 |
18.5 |
0.8～5.0 |
GY100-315 |
100 |
32 |
65 |
45 |
1.2～6.0 |
GY100-400 |
100 |
50 |
55 |
55 |
1.2～6.0 |
GY125-250 |
200 |
20 |
77 |
30 |
1.2～6.0 |
GY125-315 |
200 |
32 |
75 |
45 |
1.2～6.0 |
GY125-400 |
200 |
50 |
70 |
90 |
1.2～8.0 |
GY150-250 |
400 |
20 |
79 |
75 |
1.2～8.0 |
GY150-315 |
400 |
32 |
79 |
90 |
1.2～8.0 |
GY150-400 |
400 |
50 |
78 |
132 |
1.2～8.0 |
