air steam saw dust dryer

Specifications

Air Steam Saw Dust Dryer
Reasonable structure,
Low energy consumption
drying wet saw dust into best moisture

Air Steam Saw Dust Dryer

Saw dust Air steam dryer also knows as flash dryer/air flow drying, it is applied for the solid raw material which has flow ability.  We have the special design for drying wet moisture fiber raw material saw dust .Application Initial moisture below 50% .The whole saw dust drying machine is consists of Hot wind Stove ,Material feeder ,Drying Pipe .Drying Cyclone .Cyclone separator ,Fan ,Control system ,This saw dust drying system could drying the damp saw dust into optimal moisture 8-14% for making wood briquette and wood pellet production .



Principle of Work

The damp/wet fiber  raw material like saw dust from saw mill or after crushing wood particle  through the material feeder conveyer to the drying pipe .and flue gas or heated fresh air enter into the drier at the same time.They are mixed fully.The damp saw dust are passing the drying pipe .Then the wet moisture will be separate from the material . The dried finished products discharged from cyclone separator, the whole system could be operated at Negtive pressure air pressure of the fan .our special design could have excellent drying result; we have more than 20 years working experience.



 Drying Temperature Technical Consultation and Test



The inlet hot air temperature could be 100- 180 °C.



The outlet hot air temperature could be 80-100°C



Mostly the temperature will be depends on the damp/wet initial moisture and special character .



Application:
1,Drying the damp /wet saw dust into optimal moisture (8-14%)for making wood briquette .



2,Drying the damp/wet saw dust into optimal moisture (8-14%)for making biomass wood pellets



3,Drying the wet wood flour into best moisture(below 3%) for making WPC products



Feature:
1. Energy saving2. Wide use for wood briquette production/For wood pellet production/For WPC production
3. Good drying effect4. Low noise 5,Less burning fuel





 XW-H-350 Type Saw Dust Air Steam Dryer Main Technical Parameter

(Screw Conveyor Machine + Screener Machine)

Name	Saw Dust Air Steam Dryer
Model	Xw-h-350
Application Initial Moisture	30%-50%
Final Drying Moisture	8-14%
Drying Capacity	400-500Kg/H
Fan Power	11KW
Fan Wind Capacity	8960 m³/h
Drying Pipe Diameter	350mm
Drying Pipe Material	steel plate
Thickness Of the Drying Pipe	2.5mm
Direct Burning Hot Wind Stove Size	1650*900*1200mm
Fuel (firewood) Consumption	40-50kg/h
Max Height Of the Drying Pipe	3.8-4 Meters
Saw Dust Drying Travel Distance In Drying Pipe	35Meters
Machine Weight	3000kg
Screw Conveyor Machine  Power	0.75KW
Saw Dust Screener Machine Power	0.75Kw
Power Supply	3 Phase 380V 50Hz Single Phase 220V
One Control Cabinet	Control Screw conveyor /screener/Dryer Fan
Package	Elastic Film Package
Delivery Time	15-20 days
