Product Details
Place of Origin: | Jiangxi, China | Type: | Ceramic Plates | Application: | Industrial Ceramic |
Material: | Alumina Ceramic | Model Number: | honeycomb | Brand Name: | ZY |
Product Description
Specifications
1)20 years professional manufacture2) Alumina Ceramic honeycomb
3) Ontime delivery
4) One-stop service
5) ISO9001:2000
Ceramic honeycomb
It is one kind of industrial porous ceramics, many passable parallel channels are ramified over its inside.
Each individual part made up of these honeycomb ceramics are constructed into the shape with square cells at two ends.
Compared with ordinary ceramic materials, they are characterized by low heat expansion ratio, high thermal shock resistance, large specific surface area, anticorrosion etc .
Ceramic honeycomb
regenerator is the key and core component on high temperature air combustion technology. It has large specific area, specific heat, low coefficient of thermal expansion.
Ceramic honeycomb Application:
It can be used as heat-exchanger and apply into the RTO of heat recovery devices .
It can be used as catalyst supporter to purify Automobile exhaust and remove
abnormal flavour of gas.
It can be used as filters and apply to food service industry, environmental protection industry and Metallurgical Industry .
Technical data:
| Type Performance | Alumina porcelain
| Mullite porcelain
| Dense cordierite porcelain
| Loose cordierite porcelain | Mullite cordierite porcelain | Stoneware porcelain
| |
Chemical composition
| AL2O3 | 48-55 | 66-72 | 32-36 | 32-37 | 55-65 | 20-26 | |
SiO3 | 40-45 | 25-30 | 45-52 | 46-52 | 28-36 | 68-75 | ||
MgO |
|
| 5-8 | 8-12 | 2.5-3.2 | 0.2-0.3 | ||
K2O+Na2O+CaO | 4.0-5.5 | ≤1.0 | ≤3.0 | ≤2.0 | ≤1.0 | 2.5-4.0 | ||
| Density g/cm3 | 2.7 | 2.9 | 2.4-2.6 | 1.9-2.0 | 2.9-3.2 | 2.3-2.5 | |
Coefficient of thermal expansion (20-100°C)*10-6·°C | 5-7 | 5.5-6.5 | 2.5-3.5 | 1.3-2.5 | 2.5-4.0 | 5-7 | ||
Calorific capacity(20-1000°C).J/kg·°C | 800-900 | 1100-1300 | 800-1200 | 750-900 | 850-1100 | 840-920 | ||
Thermal conductivity (20-1000°C)W/m·°C | 1.5-2.5 | 1.5-2.0 | 1.5-2.58 | 1.3-1.5 | 1.5-2.3 | 1.0-1.2 | ||
Thermal shock resistance °C | ≥150 | ≥350 | ≥250 | ≥360 | ≥250 | ≥150 | ||
Max working temperature °C | 1300 | 1600 | 1300 | 1300 | 1400 | 1300 |
Alumina Ceramic honeycomb
Type Item | 1 | 2 | 3 | 4 | 5 | 6 |
End hole number | 5*5 | 13*13 | 20*20 | 25*25 | 40*40 | 50*50 |
Hole density cm-2 | 0.15 | 1 | 2 | 3 | 7 | 11 |
Aperture mm | 26.3 | 9.2 | 6.4 | 4.9 | 3.0 | 2.3 |
Thickness mm | 2 | 1.5 | 1.2 | 1.0 | 0.7 | 0.7 |
Surface area m2/m3 | 117 | 278 | 455 | 540 | 825 | 1005 |
Opening rate % | 77 | 74 | 73 | 67 | 65 | 57 |
Size mm | Standard: 150*150*600/450/300/150/100/50 Other: 100*100*100/40 |
Our advantage:
1.Handle in this line for 20 years,It's a very professional company.
2.Patient Saler can give you best service.
3.Have our own factory,can offer you the best price and one-stop service.
4.ISO9001 certification available.
5.We offer free samples, with shipping and taxes paid by the buyer.the paypal payment way is acceptable for samples.
Cylindrical Ceramic honeycomb ,small ceramic honeycomb,
Welcome to inquiry!
