SIC Ceramic Plate, Big Size>400mm

Specifications

1. Size can be order.Material: Alumina, SIC, Porous Ceramic
2.Good permeability rate,high temperature resistance, high strength







1, Porous Creamic Plate product overview:



       ceramic Brick are by many size distribution uniformity, interconnected bridge arch open hole composition, when fluid from these zhongtong obsolete, fluid of the suspended substance, colloid particles, macromolecular organic matter and interception and adsorption in microchannel inside, so as to achieve the purification and filtration homogenization effect.



2, characteristic: corrosion resistance, high temperature resistance, high strength, low resistance, non-toxic, long service life.



3, Porous Ceramic Plate specific application:



   It widely used in chemical industry, metallurgy, power plant, coking, the nuclear industry and so on industry wastewater, waste gas purification treatment process. Especially suitable for power station boiler, industry boiler desulfurization dusting and coal yard waste water purification filter engineering, with "precipitation + microporous ceramic filter" new processing, suspended solids removal rate can reach 91-97%, export suspended matter in 10 to 50 mg/L, COD removal rate is 65%, and the water quality clear transparent, achieve closed-circuit circulation use of zero discharge purposes.



4, Porous Ceramic Plate main technical index:
(1) the capacity is heavy: 1.4 ~ 1.6 g/cm3
(2) the hole diameter: 10 ~ 500 μ m
(3) porosity: 30 ~ 50%
(4) the flexural strength: 3.5 ~ 5.0 MPa
(5) the compressive strength: 12 ~ 15 mpa
6 Morse hardness: 6 ~ 8 Scal
7 permeable rate: 1.0 ~ 2.5 t/m2. H
7 permeability rate: 1.8 ~ 2.5 m3 / m2h. H
9 acid degree: 98% or more
10. alkali resistance rate: 82% or more
11.heat temperature: 800 ° C



SIC Ceramic Plate Production Progress:
