Ozone Generator Commercial Grade/ozone Sanitating System/ozone Sanitation Machine
US$ 4,500 - 5,000,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
Quanju
Model Number:
QJ-8005Y-80A
Payment & Shipping
Payment Methods:
Port of Shipment:
HK/GZ/SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Ozone Generator for Swimming Pool, Water Purifier System, Ozone Generator for PondUS$ 1,050 - 2,000MOQ: 1 Unit -
Low Price Industrial 300g Oxygen Ozone Generator for Water TreatmentUS$ 11,000 - 12,000MOQ: 1 Unit
-
o3 Disinfector Machine, Ozone DisinfectorNegotiableMOQ: 1 Unit
-
Quanju Water Purification Machine,purification Machine Used in Large IndustryUS$ 11,000 - 12,000MOQ: 1 Unit
-
Swimming Pool Ozone/water Ozonator ChinaUS$ 4,500 - 5,000,000MOQ: 1 Unit
Brand Name
Quanju
Model Number
QJ-8005Y-80A
ozone generator commercial grade/ozone sanitating system/ozone sanitation machine
Application of ozone
- Drinking water , mineral water ,cooling water , swimming recycled water , secondary water supply , industrial water etc .
- Sewage treatment , COD degradation , bleaching treatment , bleaching , bleaching , water , sewage , waste water ,waste gas etc
- Hospital sewage and other industrial water , sterilization , deodorization in addition to taste ; phenol , sulfur , iron and other metal ion in waste water treatment ; especially for the biological toxic, biodegradable pollutant treatment to improve its biological activity , a special effects.
Ozone use for agriculture.
Ozone use for washing bottles
Ozone use for waste water treatment
Field use figure
Product Description
Characteristics:
- Technology corona discharge ozone generator, with high ozone concentration and longlife time, with 220-240V/Hz
- with air source exchanged interface ,could be self-oxygen feeding or air feeding
- Design with small size , easy taking and light weight
- Volume of ozone machine is small in the industrial , installation area is not restricted
- Inner PSA high purified oxygen generator
- Water cooling and air cooling system ,efficiently heat release easy,high ozone concentration and high safety
- Ozone concentration adjustable
- Thermal -shutdown and over voltage protection
- Easy operation : ozone system switch and air pump switch
- High ozone concentration output ,high output pressure and suitable for varied kind water treatment
Technical Specifications:
QJ-8005Y-80A
| Product model | Ozone production | Ozone concentration | Power rating | Weight | Dimension | Cooling-down method | Gas source |
| QJ-8005Y-80A | 80g/h | 60-80mg/l | 1750W | 86kg | 550*400*1380mm |
Air cooling+ water cooling |
Built-in oxygen generation system |
Oxygen feed ozone generator
| Product model | Ozone production(g/h) | Ozone concentration | Power rating(W) | Weight(Kg) | Dimension (mm) | Cooling-down method | Gas source |
| QJ-8001Y-10A | 10 | 60-80 | 680 | 43 | 550*400*730 | Air cooling | Built in oxygen geeration system |
| QJ-8002Y-15A | 15 | 60-80 | 780 | 48 | 550*400*880 |
Air cooling+ water cooling |
|
| QJ-8002Y-20A | 20 | 60-80 | 580 | 50 | |||
| QJ-8002Y-25A | 25 | 60-80 | 900 | 52 | |||
| QJ-8003Y-30A | 30 | 60-80 | 950 | 55 | 550*400*1030 | ||
| QJ-8003Y-40A | 40 | 60-80 | 1100 | 60 | |||
| QJ-8004Y-50A | 50 | 60-80 | 1200 | 75 | 550*400*1330 | ||
| QJ-8004Y-60A | 60 | 60-80 | 1300 | 80 | |||
| QJ-8005Y-80A | 80 | 60-80 | 1750 | 86 | 550*400*1380 | ||
| QJ-8006Y-100A | 100 | 60-80 | 2650 | 107 | 600*500*1430 | ||
| QJ-8007Y-150A | 150 | 60-80 | 3200 | 152 | 700*750*1430 | ||
| QJ-8008Y-200A | 200 | 60-80 | 3600 | 157 |
Packaging & Shipping
Packaging : carton /wooden case
Shipping: 5-7 days after payment confirmed
Our services
- Before using, please read the instruction carefully before operation of unit.
- Machine should be installed in a dry, no duct, humidity, and good ventilation.
- Machine crash is prohibited. Keep cleaning of inner external case.
- Turn off the power cord and ozone concentration adjustment if machine is left unused for a long period of time.
(Always disconnect the power cord from the electrical outlet before cleaning or maintaining your appliance.)
Company infromation
Guangzhou Quanju Ozone Technology Co.,ltd which has been in ozone manufacturing for more than 12 years and we supply 500mg/h-2kg/h air feed ozone generators,PSA oxygen generators and car ozone anion air purifiers.
Contact us
Email:vincy @ozonemade.com
Skype : ozonemade-vincy
Whatsapp:8613660343903
Website: /
Send Inquiry to This Supplier
Business Type
Manufacturer
Year Established
2010
Factory Size
1,000-3,000 square meters
Total Employees
51 - 100 People
