Marine Angle Stop Valve
Marine Angle Valves/ Angle Stop Valve
Marine Cast Steel Screw Down Check Angle Valve also can be called as Marine Cast Steel Angle SDNR Valve or SDNR Angle Valve. It is suitable for the pipe system with the medium fresh water, air & other gas, oil and steam with the temperature not over 300 centigrade degree.
Main Material:
Body: Cast Steel (SC480)
Bonnet: Cast Steel (SC480)
Packing Gland: Bronze (BC6) or Stainless Steel (2Cr13)
Stem: C3771BD (Brass) or SUS403
Seat: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)
Disc: Bronze (BC6) or Stainless Steel (2Cr13, SCS2)
Gasket: non-asbestos
Handwheel: Cast Iron (FC200)
Standard:ISO,JIS,DIN,ATSM,CB/T,GB,BG/T,CBM Certificate:CCS,ABS,BV,DNV,GL,LR
The main performance specifications:
| DN | L | D2 | H | Flanged Size | Weight(kg) | |||
| D | C | n | h | |||||
| 15 | 55 | 80 | 120 | 80 | 60 | 4 | 12 | 1.98 |
| 20 | 60 | 100 | 130 | 85 | 65 | 4 | 12 | 2.73 |
| 25 | 65 | 125 | 145 | 95 | 75 | 4 | 12 | 3.44 |
| 32 | 80 | 125 | 150 | 115 | 90 | 4 | 15 | 4.77 |
| 40 | 85 | 140 | 165 | 120 | 95 | 4 | 15 | 5.99 |
| 50 | 100 | 140 | 200 | 130 | 105 | 4 | 15 | 10.1 |
| 65 | 115 | 160 | 220 | 155 | 130 | 4 | 15 | 15.6 |
Marine Angle Valves/ Angle Stop Valve
Our product Categorie:marine check valve,marine globe valve,marine gate valve ,marine ball valve,marine butterfly valve,marine hose valve, marine check globe valve, marine angle valve,marine screw down check globe valve, marine valve,marine cock, marine pipes,marine fittings,marine accessories.
Other Related Valves:
Valves: Butterfly Valve ; Globe Valve ; Gate Valve ; Check Valve ; Angle Valve
Water Pump: Centrifugal Pump; Vortex Pump ; Jet Pump ; Bilge Pump
Sewage Pump: Submersible Sewage Pump; Sewage Crushing Pump
Fire Pump: Portable Fire Pump; Fixed Fire Pump ; Diesel Emergency Fire Pump
Oil Pump: Gear Oil Pump; Hot Oil Pump; Self-priming centrifugal oil pump
Other Biman Valves
Why Choose BM
A. Excellent service before purchasing
B.M know what the best cost-effective products are. According to clients’ circumstances, we will offer most suitable products for them.
B. Guaranteed quality
Most products which B.M offered are with high quality and also provide warranty to security benefits.
C. Rich experience and Customized Products
B.M has enormous resources of various marine equipment. All of our products are customized.
We can offer products according to your detail equipment and drawings.
FAQ
How to order Valves from Biman?
- Please tell us the Size, Pressure and Quantity and other request you need.
- If you have the certificate requirements, please let me know.
- We'll make quotation for you. After your confirmation, PI will send to you.
- We'll arrange the order for you after receiving your payment
- After the goods finished, we send the goods to you and tell you the tracking number.
