Camda gas plant equipment
Camda gas generator:
Acceptable working conditions:
Ambient temperature : -10°C---+40°C
(antifreeze or hot water needed for below -20°C)
Relative humidity: less than 90% (20°C)
Altitude: no more than 500m
Normal working conditions:
Genset can run at rated power on the conditions:
Atmospheric Pressure: 100kPa, Ambient Temp: 20°C, Relative Humidity: 30%.
Applied gas:
Natural Gas and Biogas
Acceptable fuel gas pressure: 2 to 10kPa
CH4 content: for natural gas no less than 85%
Gas heat valueno less than 5500kcal/Nm3 (23MJ/Nm3 ).
Genset output power will increase as the gas heat value increase, if use low heat value gas for fuel ( if Heat value less than 5500kcal/Nm3) it will lower the power efficiency.
Gas doesn’t include free water or free materials (the size of impurities should be less than 5μm.)
H2S content should no more than 200mg/Nm3
NH3 content should no more than 20mg/Nm3
Impurities content should no more than 30mg/Nm3; size≤5μm
Water content should no more than 40g/Nm3, no free water.
Power range:
Relative configuration:
Alternators
Parts on engine:
Standard Scope of Supply for gas generator:
1.Brand new gas engine, 90% parts include engine body , crank shaft, cam shaft, piston, cylinder head, etc made by Cummins, Daewoo and Man with best quality
2.Brand new brushless France Leroy Somer alternator
Rating: 3 phases 4 lines. 400/230V, 50 HZ , 1500rpm, 0.8PF, IP22-23, Insulation class H
3.Radiator for 40°C/50°C ambient temperature
4.Ignition system adopted USA ALTRONIC
5.Emergency stop mounted
6.Battery,Battery cable and Battery charger
7.Standard tool box
8.Standard Accessory for installation (include bellows,silencer,flange,asbestos pad,Anti-rust water,screw )
9.Gas Train include Regulator valve,Electromagnetic Valve, Fire arrestor,Ball Valve (Chinese brand)
Gas scrubber:
The main function of this system
1. Desulfurization
2. De-dust
3. De-water
4. Increase pressure
5. Steady pressure
6. Change desulfurizer without stopping genset
Configuration:
1. Desulfurizing tower
2. Separator
3. Water condenser
4. Blower
Packaging:
Wood case or plastic package
Seaport: From Shenzhen Port or Guangzhou Port to any port all over the world.
12 months or 8000 running hours warranty covering all manufacturing defects (whichever comes first)since reaching destination port, our company provides free easily-damaged parts for the faults caused by the quality of products or raw material, but exclude the damageable parts of engine due to customer's incorrect man-made operation. After expiration, our company provides spare parts with cost for maintenance forever.
Projects Overseas
Australia:
Model:KDGH120-G
Type:Biogas
Commission Time:May,2013
QTY:3 Sets
In Sweden
Model:KDGH50-G
Type:Biogas
Commission Time:June, 2012
QTY:1 Sets
In UK
Model:KDGH120-G KDGH50-G
Type:Natual gas
Commission Time:Dec,2012
QTY:3 Sets
In Kenya
Model:KDGH120-G KDGH50-G
Type: Biogas
Commission Time:Dec,2012
In Russia
Model:KDGH120-G
Type:Natual gas
Commission Time:Dec,2012
QTY:4 Sets
Payment terms
1.T/T. Pre-pay 20% for starting production, pay up balance before delivery.
2. Confirmed and Irrevocable L/C at sight.
Delivery time
30 days after prepayment or L/C received
