80kW Natural gas/Biogas/LPG/Syngas/Oil gas/Coal mine gas generator

Features of Camda H series gas genset

l Experiment- evidential gas engine technology

l overhaul term: 18000~25000 hours

l Over 85% co-generation efficiency

l Economical and low-cost running: lower gas and oil consumption

l Specially-designed air valves, crankshaft, camshaft, pistons,ignition system and combustion chamber according to international brands gas engine technology(Waukesha, MAN, Guascor, Daewoo)

l 4 air valves design for each cylinder, sufficient air intake and exhaust, more air intake, to realize higher power output and stronger capability of load

l Electronic Air/Fuel Ratio mixer, better combustion and lower emission, sufficient combustion to reduce gas consumption and increase engine heat efficiency, effectively lessen NOX emission.

l Original Cummins engine body, 90% parts made by Cummins China factory, long life and durable engine parts produced strictly accord toISO9001-2000 International Quality Management System

l Unique air-fuel ratio adjusting system adapting 30%~70% CH4 Methane concentration

l Integrated Crankshaft Forging for gas engine made by Cummins, different from other China brands which the crankshaft is forged by subsections and then assembled into a whole.

l Continuous rating up to 90% of prime power rating.

l Exceed 10-year genset repair and maintenance experience

l Low pressure gas intake, biogas no need boosting pressure

l Larger displacement engine to keep much surplus for genset power output.

l Sound alarm and protection system

l Electrical efficiency higher 10%~20% than other China brands

l With good command of biogas anaerobic technology, we can make better biogas genset, design and testing.

l ISO standard production

l Adopting high-precision special gas engine speed governor: precise speed governing, instant recovering ability so as to fit different loads upon the three signals: rotating speed, load and temperature.

l Precisely-controlled engineair intake and exhaust time.

l Advanced ignition sensor and ECU (Electronic Control Unit) ignition system with computer core:

Precise ignition at right cylinder and right time, prompt startup ability to avoid the ratio of detonation and make stable engine.

l Cylinder Block: High quality alloy cast iron for the rigidity performance and good stability.

l Crankshaft and Rod: Robust and fully balanced crankshaftdesign for a more steadilyrotation and higher strength.

l Lubrication System: Dual spin-on filter can separateimpurity above 10um effectively and lower cost.

l Less accumulated carbon, reduces the abrasion between cylinder and valve, it canmuch prolong genset lifetime.

l Compact design: small size and weight

l Wide spare parts availability: Base on Cummins engine parts, the engine base body made of the parts from the supplying factory for Cummins engine China factory.

l Equipped with the most well-known brand generator—Leroy Somer.

l Using advanced intelligent PLC genset controller: capable computer chip, with full monitoring, control, alarm and protecting function, all-in-one configuration for all kinds of demands.

l Electrical system: 24V cranking motor starting and battery charging system.

l Self-contained power genset, needs few accessories.

l Parallel operation with genset or city power grid for option.

l Instant startup configuration for option.

l Free of charge training for operation and maintenance. (at Camda headquarter)
