Specifications
The system use TH701 series desulfurizer, which use Iron oxide as the main active constituent, make into high aaefficiency biogaBiogas Scrubber/ Biogas purification system/ Biogas pretreatment system
1. Application field
The skid-mounted biogas pre-treatment system adopts the dry desulfurization system which is applicable for small industrial devices whose H2S is less than 2000ppm. The biggest skid-mounted pre-treatment system can deal with 300Nm3/h biogas and we suggest it to be used in farmland which can equipped with CHP system. In the industrial waste water biogas project, if the devices has to run long time in a day, the H2S is high and has to synchronize with the nation grid, the biogas dry desulfurization system has to be designed specifically.
The application domains equipped with small biogas generator set:
Pig farm with more than 3000 pigs
Cow farm with more than 500 cows
Chicken farm with more than 10000 chicken
Biogas collected from more than 200 peasant households can be used to generate electricity.
2. Application Environment
The working area ambient temperature should be in the range of 0 ~ 50 °C due to the drained water from the pre-treatment. If there is any underground sewage wells, the system has to anti-freezing and anti-cracking. This system is better to be installed in a well-ventilated room.
| Model | KDCL-50-WQ | KDCL-100-WQ | KDCL-200-WQ | KDCL-300-WQ |
| Gen Set power(KW) | 24-50 | 80-120 | 150-200 | 250-300 |
| Gas flow(Nm3/h) | 30-50 | 50-100 | 100-150 | 150-200 |
| Pressure(kpa) | 10 | 10 | 10 | 10 |
| Desulfurizer Model&size |
2 pcs KDTL-250-G |
2 pcs KDTL-400-G |
2 pcs KDTL-800-G |
4 pcs KDTL-800-G |
| φ500×1880 | Φ600×2000 | Φ800×2200 | Φ800×2200 | |
| Water seperator Model | KDFC-200-G | KDFC-400-G | KDFC-400-G | KDFC-400-G |
| Gas Blower Model&Power | NSR50-50A 1.1KW | NSR65-65A 1.5KW | NSR80-80A 2.2KW | NSR100-100A 3KW |
| Inlet&Outlet Flange |
DN50 PN10 |
DN65 PN10 |
DN80 PN10 |
DN100 PN10 |
|
Ferric Oxide Q.TY |
2*150kg | 2*300kg | 2*500kg | 4*800kg |
Replacement(Hours) |
1500 | 1500 | 1250-1500 | 3000-4000 |
| Dimension(mm) | 2000×1600×2160 | 2000×2000×2160 | 2500×2000×2250 | 4200×2000×2280 |
