3G Industrial WIFI Router WCDMA Vehicle Telematics Gateway

Name: 3G Industrial WIFI Router WCDMA Vehicle Telematics Gateway
Brand: Caimore
SKU: 138276409
Availability: InStock

US$ 100 - 300 MOQ: 1 Piece

Key Specifications

Place of Origin:

Fujian, China

Brand Name:

Caimore

Model Number:

CM8151G

Xiamen Caimore Communication Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xiamen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Fujian, China

Brand Name Caimore

Model Number CM8151G

Specifications

gateway
1. 5XLAN
2. Industrial design
3. Wifi module
4. 1 WAN port PPPOE communication

INDUSTRIAL 5xLAN WCDMA 3G GATEWAY

WIFI Wireless parameters

Item	Content
WIFI module	WIFI module chip-embedded, high integration, good stability
WIFI standard	Support 802.11 a/b/g/n standard, speed, support 6M/9M/12M/18M/24M/36/48/54Mbps,up to 108M
Encryption	Supports WAP encryption, Support WEP encryption
AP mode	Support AP mode
Transmission distance	Outdoor non-stop, outdoor coverage up to 150 meters

WCDMA Wireless Parameters

Item	Content
Wireless module	use industrial wireless module
Standards and frequency bands	Support UMTS/HSDPA/WCDMA 850/900/1900/2100MHz Dual-band EGSM 850/900/1800/1900MHz Support GPRS/EDGE CLASS 12
Coding scheme	HSDPA/HSUPA/WCDMA/EDGE/GPRS/CSD mode
Communication bandwidth	HSDPA/HSUPA mode:Downlink up to 7.2Mbps,Uplink up to 5.76Mbps WCDMA mode:Downlink/Uplink up to 384Kbps
Transmit power	<24dBm
Receiver sensitivity	<-109dBm
Function support	Support data, voice, SMS and fax

Interface Type:

Item	Content
WAN port	one WAN port (Line0), supports PPPOE
Ethernet port	Four 10/100 Base-T Ethernet port(LAN1-LAN4), Ethernet IEEE 802-3, 802-2; built-in 1.5KV magnetic isolation protection
Serial port	1 RS485 interface 1 or RS232 serial port (support RS422/TTL) Data bit: 7,8 bit Stop bits: 1, 2-bit Parity: no parity, odd parity, even parity, SPACE and MARK parity Serial speed: 110bps ~ 230400bps Flow Control: None flow control, RTS / CTS hardware flow control or XON / XOFF software flow control
USB interface	one USB interface, USB2.0, HOST interface, speed at 12Mbps
Indicator LED	“POWER” , wide area network “WAN”, communication “COMM”, “WIFI”, Ethernet port and online “LINK / ACT” indicator
Antenna Interface	Standard SMA female interface, 50 ohm; optional 3M/5M/10M/15M antenna extension cable, meet the different needs of customers
UIM interface	1.8V/3V/5V standard putter user card interface, built-in 15KV ESD protection
Voice Interface	Standard headset interface (requires software)
Power Interface	Standard 3-pin power jack
RESET button	Reset button to restore factory settings
