Specifications
ADSL modem1. Support languages sending & receiving,
2. Support wireless internet access
3. AT command
4. RS232
Industrial CDMA ADSL modem RS232/SMS/sim card
I. Introduction
Caimore CDMA MODEM is a standard industrial design wireless device (type: CM6600), which is based
on CDMA network, adopts industrial wireless module and supports data and short message function.
CM6600 has been widely used in financial transactions, water conservancy, post transactions, smart grid,
environmental monitoring, meteorological monitoring, etc.
Product interface diagram
Accessories photos
II Product characteristics
Industrial Design:
1. industrial wireless module;
2. strengthened circuit board;
3. industrial components;
4. industrial power
III.Wireless parameter
v Support IS-95 A/B and CDMA2000 1xRT wireless network 800MHz single-band;can select 450MHz single-band or 800/1900MHz dual-band
v Support 13K QCELP Audio Codecs
v Support DTMF
v Support data, short message function
v Standard AT command
IV. Technical index
1.Interface:
v USB interface
v Standard RS232 serial port, serial speed rate 110~230400BPS
v Indicator: POWER and on-line indicator
v Antenna interface: Standard SMA female interface, 50 ohm
v SIM card interface: 1.8V/3V standard putter user card interface
v Power interface: Standard 3-pin power jack
v Voice interface: Standard headset interface (requires software)
2. Power supply:
v External power supply: DC 9V 500mA
v Wide voltage design: DC5-35V
v Communication current: 250mA
v Standby current: 20mA
3. Industrial wireless module
4. Size
v Product dimensions : 81*55*20 mm ( not including the antenna and the fixed parts)
v Package size: 298*226*60mm
5. Weight: 0.41kg
6. Other parameters:
v Operating temperature: -25 °C ~+65°C
v Storage temperature: -40~+85oC
v Relative Humidity: 95 %( No condensation )
V. The typical applications
VI. Certification and Honor
Item |
Contents |
Honors |
The enterprise was awarded "Best Supplier of Customer Satisfaction in China's Industrial Control Sector" in 2011; Company's GPRS DTU product was named "Innovation Award" |
High-tech enterprises |
Certified as state high-tech enterprises in 2010 |
Dual Soft Enterprise |
certified as state dual-soft enterprise |
Copyright |
The company has a patented technology to keep the device stable and eight copyrighted software certificate |
Offices |
nine regional offices to provide customers with convenient services |
Registered Capital |
registered capital 5 million; high-tech enterprise supported by Xiamen City |
Historical Precipitation |
11 years industry R & D accumulation and application |
