Specifications
3g router1. Support VPN, firewall
2. Industrial design
3. 4 RJ45 Ethernet port
4. Three-tier system protection
Industrial 3g Router, Industrial TD-SCDMA Router, Industrial wireless router
I. Introduction
Caimore industrial 4lan TD-SCDMA router(type:CM8255R), is a wireless router by using TD-SCDMA 3G networks, with
industrial design and 4 RJ45 Ethernet port.
II product characteristics
Powerful Function
1.Supports Ethernet data communication and packet forwarding, also supports serial port TCP / UDP
transparent data transmission or serial configuration
2.Support VPN tunnel, including PPTP, MPPE, L2TP, GRE and IPSEC
3.Intelligent anti-dropped
4.Support IPTABLES firewall, packet filtering
5.support Regular on-line offline functionality
6.Support a variety of trigger and offline modes
7.Support dynamic routing and static routing, RIPv1, RIPv2, OSPF, BGP, NDSP, IRMP, SNSP, IGMP,
DVMRP, PIM-SM/DM
8.Support multiple protocols
10.Supports NAT port mapping function
11.Support DDNS(Dynamic Domain Name Server)
12.Support DMZ
13.Support the APN / VPDN network
14.Convenient WEB configuration, Remote WEB Management
15.Support WEB configuration save and restore
16.Support telnet management, user-friendly console shell interactive environment
17.Support multiple terminals sharing router ppp wan
18.Support multiple wireless dial-up mode
19.Support as a PPP server, multiple authentication methods, support mutual authentication
20.Easy to use COM and SYSLOG System diagnostics, debugging
21.Support Serial port local software upgrades
22.Supports TFTP remote software upgrade
23.Support real-time clock
24.Support both LINUX and WINDOWS operating systems
III. Wireless parameters
Item |
Content |
Wireless module |
use industrial wireless module |
Standards and frequency bands |
TD-SCDMA/HSDPA/HSUPA:2010~2025MHz |
Coding scheme |
TD-SCDMA/HSDPA/HSUPA/EDGE/GPRS mode |
Communication bandwidth |
Downlink (Max up to 2.8Mbps) |
Transmit power |
<24dBm |
Receiver sensitivity |
<-108dBm |
Function support |
Support data, voice, SMS and fax |
Interface Type
Item |
Content |
Ethernet port |
4xLAN(Four 10/100 Base-T Ethernet ports), Ethernet IEEE 802-3, 802-2; built-in 1.5KV magnetic isolation protection |
Serial ports |
1 RS232 serial port or 1 RS485 interface (supports RS422/TTL) software flow control |
Indicator |
With “POWER”, connecting “Link / ACT”, communication “COMM” and “ONLINE” indicator LED |
Antenna Interface |
Standard SMA female interface, 50 ohm |
UIM interface |
1.8V/3V/5V standard putter user card interface, built-in 15KV ESD protection |
Voice Interface |
Standard headset interface (requires software) |
Power Interface |
Standard 3-pin power jack |
Typical Applications
