Stone Vibrating Feeder

Specifications

Stone Vibrating Feeder can send the stuff into the crusher continously,it is widely used in mining,building-material,silicate ..

Stone Vibrating Feeder

Our stone vibrating feeder is a kind of linear direction feeding equipment.It can send the stuff into the crusher continously.It is widely used in mining,builing-material,silicate and chemical industry in the crushing and screening plants.

Features:1).Smooth vibrating.

2)Reliable in operation;

3)long service life;



Model List and technical parameter of stone vibrating feeder

Model	Max.Input Size(mm)	Hourly Capacity(t)	Power(kw)	Installation Slope	Weight(kg)	Overall Dimension(mm)
GZD850x3000	500	120	3.7x2	5	3607	3110x1800x1600
GZD-1000x3600	600	150	5.5x2	5	3895	3850x1950x1630
GZD-1100x4200	780	240	5.5x2	5	4170	4400x2050x1060
GZD-1100x4900	800	280	7.5x2	5	4520	5200x2050x1700
GZD-1300x4900	800	250	11x2	5	5200	5200x2350x1750
