Specifications
Sand Making Machine1. High quality
2. Nice performance
3. Long service time
4. Reasonable price
Sand Making Machine
Description of Sand Making Machine:
1. PFC series of energy-efficient sand making machine is our company's third-generation Sand, based on the self-developed a new type of professional sand equipment.
2. It combines the existing hammer crusher, Impact Crusher of the advantages of an integrated system of sand from users of the many advantages, set hammering, counterattack, one stone at stone as one complete, finished out of sand the rate of 70% or more.
3. The fineness can be adjusted, hammer and long service life, replacement of four can use leak under the regulation of protective devices fitted to the hammer, the next section of the life of leakage increased more than 10 times, reducing the number of repairs, replacement easy damaged pieces of convenient, fast, greatly reduces the cost of sand to improve work efficiency.
4. Markedly improved after the economic benefit users by various industrial customers praise sand, typical for the current system of sand industry, is the hammer crusher, Impact Crusher, sand making straight-through alternative products, especially for river pebbles, quartz stone, flower just rock, iron ore, bauxite, basalt, etc.
Main technical parameters of Sand Making Machine:
Picture of Sand Making Machine:
| Model | The size of Feeding Port(mm) | The size of Feeding(mm) | The size of Discharging(mm) | The Material Seam Adjustment Range(mm) | Capacity(t/h) | Power(KW) | |
| Cement | Limestone | ||||||
| 800*400 | 400*185 | <120 | <5 | 5-20 | 20-30 | 35-45 | 37-45 |
| 800*600 | 500*125 | <180 | <5 | 5-20 | 35-40 | 45-55 | 45-55 |
| 800*800 | 550*330 | <180 | <5 | 5-20 | 35-45 | 55-65 | 45-55 |
| 1010*1010 | 1000*350 | <180 | <5 | 5-20 | 45-55 | 65-75 | 55-75 |
| 1200*1000 | 1200*400 | <180 | <5 | 5-20 | 80-110 | 80-100 | 100-110 |
| 1200*1200 | 1200*450 | <180 | <5 | 5-20 | 100-110 | 90-100 | 100-132 |
| 1400*1400 | 1500*500 | <190 | <5 | 5-20 | 100-150 | 100-150 | 160 |
| 1600*1600 | 1600*500 | <190 | <5 | 5-20 | 170-210 | 190-250 | 250 |
| 1800*1800 | 1800*800 | <190 | <5 | 5-20 | 250-270 | 280-310 | 315 |
