Specifications
Ore Washer Supplier is one of high efficiency and has the features of reasonable structure,high capacity and low consumption.
Ore Washer supplier
XSD Ore Washer is depending on the practice in sand and stone production,absorbing the leading technology home and abroad,and is widely used in sand making industry.
XSD series Ore Washer is used in building plant, quarry, concrete plant, dam building, casting-70 sand, glass factorys quartz sand and refilling pressure sand.
Stone washer is a main equipment for washing stone and sand. This stone washer is a special equipment used for cleaning the sand and stone materials in highway, railway, bridge, tunnel construction industries. It is more flexible, productive and energy saving with higher cleaning ration than other similar products in domestic.
Stone production line:
Including:
Jaw crusher
Impact crusher
Cone crusher
Hammer crusher
Vibrating screen etc
Sand making production line:
Including:
Jaw crusher
Sand making machine (VSI crusher)
Ball mill
Cone crusher
Hammer crusher
Sand washing machine
Vibrating screen etc
XSD Ore Washer Characteristics:
- High efficiency, reasonable structure, high capacity and low consumption
- The bearing device of impeller is separated from water and materials in water, which greatly protects the bearing from soaking, sand and pollutants.
- Compared with the spiral sand washing machine, the loss of fine sand and powder is minimized, and the grade and fineness can meet the standard requirments
Impeller Specification (mm) |
Ø2600x1000 |
Ø2800x1600 |
Ø3000x1600 |
Impeller Speed(r/min) |
1.178 |
1.177 |
1.179 |
Max Feed Size(mm) |
≤10 |
≤10 |
≤10 |
Capacity(t/h) |
20-50 |
50-90 |
100-180 |
Power(kw) |
5.5 |
7.5-11 |
11-15 |
Decelerator Models |
ZQ50-50-L-Z |
ZQ60-50-L-Z |
ZQ65-50-L-Z |
Overall Dimension(LxWxH)(mm) |
3255x1982x2690 |
3540x3000x2880 |
3845x3000x3080 |
