Specifications
1.Raw material:wire rod, steel rebar, round bar2.Straightening diam:6-14mm
3.Cutting length:800-8000mm
4.Speed:55m/min
hydraulic rebar straighten and cutting machine
---Introduction---
hydraulic rebar straighten and cutting machine
Bar wire straightener and cutter for bar is used to straightening galvanized wire or rebar with 4mm-16mm, and then cut it into the needed length. It can do a prepare work for the wire mesh welding machine. So it is widely accepted to the factory who is dealing wire wires and wire mesh. Also widely used in construction area.
---Main parameter---
hydraulic rebar straighten and cutting machine
Type | GT6-14 | GT-4-12 |
Straightening Dimension | Φ6-Φ14 | Φ4-Φ12 |
Wire Traction Speed | 55m/min | 55m/min |
Wire Cut Lengths | 800-8000mm(can add) | 800-8000mm(can add) |
Cutting Length Error | ±15mm | ±15mm |
Wire Straightening Degrees | ±2mm/m | ±2mm/m |
Traction Motor | 3KW-6p | 2.2KW-6p |
Straightening Motor | 11KW-4P | 7.5KW-4P |
Cutting Motor | 5.5KW-4p | 4KW-4p |
Whole Weight | 1500kg | 1000kg |
Overall Dimension | 2700×800×1200mm | 2500×800×1100mm |
---Picture showcase---
hydraulic rebar straighten and cutting machine
GongYi HengYuan Industry Co., Ltd is located in GongYi, ZhengZhou, HeNan Province—China
1. 12 months guarantee
2. patiently response and enthusiastic service
hydraulic rebar straighten and cutting machine
Outer packing: wooden case
Inner packing: iron shelf
Delievery details: within 15 days after reveiving prepayment
1. What is raw material?
Wire rod, round steel, screwed steel, steel rebar
2. What is machine usage?
Straightening and cutting
If you have any questions, welcome to contact me
