Specifications
steel cutting machinery1. Diameter:4-60mm
2. Speed: 32times/minute
3. Scope: smooth steel,flat steel,square steel,etc.
steel cutting machinery
Model |
GQ40 |
GQ50 |
GQ60 |
|
Cutting Range |
Common Carbon Steel |
≤Φ40mm |
≤Φ50mm |
≤Φ60mm |
|
Grade III Deformed Bar |
≤Φ32mm |
≤Φ42mm |
≤Φ50mm |
|
Max Flat Steel |
70*15mm |
80*18mm |
100*15mm |
|
Max Square Steel |
32*32mm |
40*40mm |
40*40mm |
|
Max Angle Steel |
50*50mm |
63*63mm |
75*75mm |
|
Punching Frequency |
32times/min |
28times/min |
29times/min |
|
Motor Power |
3 KW |
4 KW |
7.5 KW |
|
Voltage |
3 Phase 380V |
|||
Weight |
440kg±5kg |
570kg±5kg |
910kg±5kg |
|
Dimension |
1280*470*730 |
1440*500*750 |
1580*510*800 |
|
Main Advantages of steel cutting machinery
1. Safe
2. High efficiency
3. Easy to operate
The reasons to choose us
1. We are leading suppliers.We have stable suppliers and quality assurance.
2. We have engineers and developing ability.We can help solve the problems you may confront.
3. We have good credict and we ocus on the details.
