Specifications
10G 20G 30G 40G 50G ozone machine to sterilize waste water1.Outside air or oxygen feeding
2.Water cooling
10G 20G 30G 40G 50G ozone machine to sterilize waste water
Features of CH-WZQ series industrial ozone generator:
1. Carbon Steel Sprayed cabinet
2. Install with CH-PC 10-60g/hr enamel ozone generator tube, Water cooled for internal &external electrodes, effective prevent high temperature rising when the tube is discharging, for ensuring high ozone concentration.
3. Adjustable ozone output, Use high-frequency & Intelligent power supply inverse system, ozone outpt can be changed on demand to achieve accuracy control.
4. Feed air ambient or Feed external oxygen source (oxygen cylinder)
5. High ozone concentration is more 90mg/L
6. Easy to maintain and assemble
7. Control Panel: Gas flow meter ,Voltage meter ,Current meter ,Work instruction ,Power indication ,On/Off ,Ozone output adjuster ,Pressure regulator ,Trouble alarm, Emergency stop device ,Water flow switch
Application:
1. Industrial waste water treatment
2. Swimming pool water, SPA water, hot tub
3. Aquaculture, marine and aquarium
4. Drinking water, Bottle water treatment
5. Food processing
6. Indoor air control, air purify, etc
Specification:
Item |
Unit |
CH-WZQ 10G |
CH-WZQ 20G |
CH-WZQ 30G |
CH-WZQ 50G |
CH-WZQ 60G |
Flow rate of oxygen supply |
L/Min |
1-4 |
3-10 |
3-6 |
6-15 |
8-18 |
Ozone concentration |
Mg/L |
100-66 |
104-51 |
120-94 |
115-65 |
90-58 |
Ozone output |
g/hr |
6-15.80 |
18.72-30.60 |
21.6-33.84 |
41.40-58.50 |
43.2-62.64 |
Power |
KW |
0.40 |
0.40 |
0.60 |
0.60 |
1.30 |
Frequency |
KHZ |
6 |
||||
High voltage output |
V |
PP3600V |
||||
Power amplification |
A/V |
IGBT 50A/600V |
||||
Way of cooling |
Water cooled for internal & external electrodes |
|||||
Cooling water flow rate |
L/Min |
4 |
4 |
5 |
6 |
10 |
Cooling water temperature |
°C |
30 |
||||
Adjustable(Variable control) |
% |
20-100 |
||||
Power supply |
V/HZ |
220v/110v 50/60HZ |
||||
Dimension |
mm |
460×385×840 |
||||
ozone machine system for 5-600 m3 swimming pool water treatment:
