Specifications
fish farm water treatment equipment1.no power
2.long life
3.cheap and good
4.mixing ozone
fish farm water treatment equipment
Protein Skimmer Advantages for Aquaculture
1.Remove organic compounds from water
2.Increase the dissolved oxygen in water
3.Remove harmful air from water
4.Stable PH for water Mix ozone into water also has the function of sterilize, disinfect ion and remove algae from water
Protein Skimmer for Aquaculture
A Protein Skimmer removes large molecules from water. Proteins are very large molecules with very large numbers of atoms. Protein Skimmers originally got that name because they were
thought to skim protein molecules from the aquarium water. Actually it's now known that Protein Skimmers also remove other stuff from saltwater too.
Skimming removes certain organic compounds from your aquarium water, including proteins and amino acids, by using the polarityof the protein itself. Due to their intrinsic charge, water-borne
proteins are attracted to the air/water interface. This unit works by injecting numerous tiny bubbles into the water column. The small bubbles present an enormous air/water interface for the
protein molecules to cling to. The longer the bubble resides in the water, the more proteins it is able to attract. The action of a protein skimmer is often compared to the action of waves producing
sea foam.
Control Panel: Gas flow meter, Voltmeter, Ampmeter, Working Light, Power light, On/Off, Ozone adjuster, Pressure regulator, Trouble alarm, Emergency stop.
Parts of Protein Skimmer
Water input, PDO air intake device, mixing chamber, collecting pipe, sewage disposal, ozone input device, water output, glass liquid level etc.
Model |
Water flow rate |
Size |
CH-FPS-10 |
10 M3/Hr |
dia450×1550 mm |
CH-FPS-15 |
15 M3/Hr |
dia520×1800 mm |
CH-FPS-20 |
20 M3/Hr |
dia620×1800 mm |
CH-FPS-30 |
30 M3/Hr |
dia700×2100 mm |
CH-FPS-40 |
40 M3/Hr |
dia700×2400mm |
CH-FPS-60 |
60 M3/Hr |
dia850×2400 mm |
CH-FPS-80 |
80 M3/Hr |
dia920×3000 mm |
CH-FPS-100 |
100 M3/Hr |
dia1050×3000 mm |
CH-FPS-150 |
150 M3/Hr |
dia1250×3100 mm |
CH-FPS-160 |
160 M3/Hr |
dia1300×3100 mm |
CH-FPS-200 |
200 M3/Hr |
dia1350×3500 mm |
CH-FPS-250 |
250 M3/Hr |
dia1500×3400 mm |
