2014 Hot CE Approval High Pure Ceramic 7g 15g 30g 50g Air and Water Cool Ozone Generator Tube

Specifications

7g 15g 30g 50g air and water cool ozone generator tube
1.Patent
2.Low decay
3.High concentration
4.Anti-oxidation material

2014 Hot CE approval high pure ceramic 7g 15g 30g 50g

air and water cool ozone generator tube

(Model: CH-PT)



Characteristic:

Imported material of high pure ceramic, SS 316L of internal electrode, teflon connections which are best anti-oxidation material for ensuring several years running.



Features:

1.   Extremely low rate of ozone decay & high ozone concentration.

     Ozone concentration can be around 30~86 Mg/L, which is much higher than conventional products.



2.   Domestic patent product-got domestic patent in 2008.

     Air cooled for internal & external electrodes with low temperature rise of continuously working, high efficiency and stable ozone output.



3.   Low working voltage

     The working voltage is only 10% of the similar products, stable capacity but with low ozone dissipated.



4.   Small in size.

     It saves space effectively. The size is 1/4 smaller than similar products.



5.   Easy to maintain and install



Specification:    CH-PT 7-50G/Hr Item Unit CH-PT 7GM 7GA 15GA 30GA 50GA Ambient temperature ℃ 28 21.9 22 26 Ambient humidity % 37 39 38 44 Oxygen feed flow rate LPM 1~3 3~5 7~9 15~18 Ozone concentration Mg/L 70-40 66.4~53 62~53 52~49 Ozone output G/Hr 4.2~7.2    11.9~15.9 26~28.6 46.8~52.9 Power (220V)   W ≤100 ≤100 ≤190 ≤300 ≤500 Current +_10%   A 0.45 0.86 1.4 1.9 Cooling way Air cooling for external electrode,water cooling for internal electrode Cooling water flow rate LPM >2 Diameter of cooling water pipe mm ED 10 Temperature of cooling water ℃ Ambient temperature ±8℃ Diameter of cooling fan mm 1pcs Dia.150 fan 2pcs Dia.150 fan Diameter of Gas inlet/outlet mm ED 6 ED 8 ED 8 Ozone output adjust range % / 20-100 20-100 Line power supply V/Hz 110/60    220/50 Ozone tube dimensions mm 200×100×105 260×100×105 340×160×125 325×135×150 Power supply dimensions mm 177×66×53 201×86×83 212×90×95 189×146×95 210×146×62 weight of power supply KG 1.27 1.0 2.45 2.35 weight of ozone tube KG 0.91 1.35 1.9 4.3             Other product:

ABOUT US



>>What  we  do?



1.We Provide high-quality ozone generator for: Ozone generator wholesalers, Retailers and oneline shops (Ebay, Amazon...), OEM.

2.The custom-made ozonegenerator are available upon customer's idea, drawings, photos etc.

3.ODM-The modification of the ozone generator after customer's selection is accepted.



 >>Excellent after-sales service:



1. One year warranty again the manufacture defect.

2. Offer life time consultation on problems occurred.

3. 2M silicone tube and 2PCS air stone gift for any ozone machine order.

4. Report on the making process.Marketing feedbacks tracing.



>>Why choosing us?



1. 7 years production experienced .We are trusty business partner.·

2.  Quality Controlled: Quality Control personnel check the quality at every stage of production, from the incoming raw materials to the finished product.

3.  Production Capacity: 3000 pcs per month.

4.  We have serial products: ozone tube, UV water sterilizers, ozone generators, oxygen concentrators, protein skimmers, and filters, mixing pumps and other water or air treatment spare parts.

5. We supply OEM service according to customers' requests and give out professional suggestions.

6. Distributors Offer :  Welcome to be our distributor
