KIMO-NZZ AUTOMATIC MEDIUM-SPEED PAPER CUP MAKING MACHINES
Popular Advantages Of Paper Cup Making Machine:
KIMO-NZZ automatic medium-speed paper cup making machine is a multi station automatic machine producing both single and double PE coated drink cups, ice cream cups through continuous process of automatic paper feeding, sealing, oil injection, bottom cutting, heating, knurling, curling and stacking.
The paper cup making machine adipting hot air system, PLC control, servo motor driving, full-automatic failure warning, counting, detection, stopping, etc.
Features Of Paper Cup Making Machine:
• Different from other normal paper cup making machine, NZZ use special square steel heavy and good quality, much stably when running.
• Intelligent design, PLC automatic control, servo motor driving, full-automatic failure warning, counting, detection, stopping, etc.
A. The main motor use the best gear reduction unit;
B. Two times bottom paper feeding;
C. Operate panel use touch screen controlled.
• Adopt full-automatic sealed lubricating system, which ensures the long-term uninterrupted high-speed running of the paper cup making machine.
• The parts all adopt standard production, have high generality and good exchange performance, and facilitate equipment maintenance.
Main Technical Parameter Of Paper Cup Making Machine:
| Paper request | 150-350 (single & double PE paper) |
| Voltage supply | 220V~380V, 50Hz or customized |
| Cup size | 1.5~12oz |
| Speed | 60~70pcs/min |
| Paper cup top diameter | Min 38mm-Max 94mm |
| Paper cup bottom diameter | Min 30mm-Max 75mm |
| Paper cup height | Min 30mm-Max 111mm |
| Total power | 9.5kw |
| Weight | 2000kgs |
| Overall dimensions (L*W*H) | 2800*1400*1700mm |
| Main parts brand |
PLC: Mitsubishi Touch Screen: Siemens or other Ultrasonic: Evergreen (Taiwan) |
Details Pictures Of Paper Cup Making Machine:
Samples Of Paper Cup Making Machine:
Packing & Shipping Of Paper Cup Making Machine:
Advantage & Service Of Paper Cup Making Machine:
• Have several senior engineers service in many countries, all the year round, with our after-sales office in countries.
• Machines with quality guarantee for one year, life-long maintenance.
• A lot of paper cup making machines can be monitored via Internet, solve customer requirements immediately.
• Several senior engineers innovate and reform the technology continuous, in order to ensure the quality of mechanical stability.
• Undertake various non-standard machinery, solve the customers' special requirements.
Certifications:
CONTACTS:
Contact us, best price and high quality for you. Thanks!
