Specifications
1.ISO factory2.Machine:Include: punch, package wire and razor machine, wire spool, barbed wire mesh rolling part.
Description Hexagonal wire mesh machine
Gabion mesh machine
Gabion mesh machine is also called the heavy-duty hexagonal wire mesh machine. The hexagonal wire netting from it is mainly used as building material, it can be used in reservoir for closure, and also service as highway guard rail netting, railway guard rail netting, railway guard rail netting, green guard rail netting, side hill mesh case, flood fighting msh case, dike dam guard rail netting, zoo guard rail netting, mine tunnel supporting mesh, grass land mesh, etc. After Sales service
Maintenance period: one year.
The main specification of Gabion mesh:
Type | Mesh | The Max. | Wire | Twisting count | Spindle | Motor | Theoretical |
| size(mm) | width(mm) | diameter(mm) | (Roll) | Speed | power(KW) | Velocity(m/h) |
GMM23 | 60X80 | 2300 | 1.6-3 | 3 | 25 | 11 | 165 |
80X100 | 195 | ||||||
100X120 | 1.6-3.2 | 225 | |||||
120X150 | 1.6-3.5 | 20 | 255 | ||||
GMM33 | 60X80 | 3300 | 1.6-2.8 | 25 | 15 | 165 | |
80X100 | 1.6-3 | 195 | |||||
100X120 | 1.6-3.2 | 225 | |||||
120X150 | 1.6-3.5 | 20 | 255 | ||||
GMM43-2 | 60X80 | 4300 | 1.6-2.8 | 25 | 22 | 165 | |
80X100 | 1.6-3 | 195 | |||||
100X120 | 225 | ||||||
120X150 | 1.6-3.2 | 20 | 255 | ||||
GMM43-3 | 60X80 | 1.6-2.8 | 5 | 25 | 165 | ||
80X100 | 1.6-3 | 195 | |||||
100X120 | 225 | ||||||
120X150 | 1.6-3.2 | 20 | 255 |
1.Gabion machine
Motor Power:22KW
External Dimension 7500*1400*2600mm
Weight:16Ton
2.Winding machine
External Dimension: 2000*1100*1600mm
Weight:600kg
3.Loading machine
Motor Power:1.5kw
External Dimension: 7200*880*1200mm
4. Reeling machine
5. Curling machine
Width:4m
Power:4kw
External Dimension:5500*1750*1600mm
Weight:3000kg
6.Cutting machine
Powder:3kw
External Dimension: 5500*1200*1900mm
7.Pressing machine
