Overband Magnetic Separator Easy To Operate
1.Machine introduction
1.This product is very suitable for the efficient recovery and utilization of the magnetic materials from waste slurries.
2.Its magnetic system is made up of a group of bare-mounted magnets, which are arranged according to a certain gap.
3.The magnetic system has a direct effect on the magnetic materials. Under strong magnetic field intensity and a large gradient effect, the recovery rate can be as high as 85%-95%.
4.In particular, with the V-shaped scraper and their self-gravity, the magnetic materials can be discharged without water or less water.
5.This machine is widely used in metallurgy, mining, nonferrous metals, gold, building materials, electricity, coal preparation plants, iron and steel plants (steel slag), sintering plants and etc.
Application
Tailings Reclaimer of permanent magnetism is a kind of mechanical equipment in wet separation of the materials of strong magnetism in the granular of powder situation. This machine is used for recovering tailings in iron ore process. It does not run off mineral powder to make full use of effective resources.
2.Technical parameters
Model |
Processing pulp volume(m3/h) |
Recovery of ore(t/h) |
plate(piece) |
motor(kw) |
weight(Kg) |
HTO-CXJ104 |
200~300 |
2~4 |
4 |
3.0 |
1100 |
HTO-CXJ106 |
400~500 |
3~5 |
6 |
1500 |
|
HTO-CXJ128 |
600~700 |
5~8 |
8 |
4.0 |
1800 |
HTO-CXJ1210 |
700~850 |
7~10 |
10 |
2100 |
|
HTO-CXJ1512 |
1000~1200 |
11~16 |
12 |
5.5 |
3200 |
HTO-CXJ1514 |
1200~1400 |
13~18 |
14 |
3600 |
|
HTO-CXJ2012 |
1500~1800 |
14~19 |
12 |
5.5 |
3800 |
HTO-CXJ2014 |
2000~2400 |
17~22 |
14 |
4200 |
3. contact information
If you need further information, please contact us freely, we will do our best to cooperate with you.
