Automatic Hydraulic Shearing Machine Price
1.Machine introduction:
Q43 Series of Automatic Hydraulic Alligator Shear is applied in recycling companies,automobile dismantling plants,smelting & casting industry to cold cut section steel and metallic structural parts into acceptable furnace charging.
2.Machine features:
1)Hydraulic driving with easy operation,safe and reliable performance.
2)Blade length:400mm,600mm,700mm,800mm,1000mm,1200mm.
3)Eight levels of shear force:63tons-400tons.
4)No footing bolts needed during installation:use diesel engine when electric power is unavailable.
3.Technical parameters:
Hydraulic Shearing Machine(Alligator Type) HTO-JQJ1600 | ||||||
Power System(motor) |
model |
Y180L2-4 |
Hydraulic System(gear pump) |
model |
CBG-60 |
|
rated power |
18.5kw |
nominal displacement |
60ml/r |
|||
rated rotor speed |
1470pm |
rated pressure |
31.5MPa |
|||
Control System |
electro-hydraulic directional control valve,button control |
working parameters of system |
Max shear power |
160 tons |
||
Max press material |
22 tons |
|||||
shear frequency |
6-10 times/minutes |
|||||
Maximum Shear Specifications |
angle steel |
140*140*10(3 pieces) |
||||
joist steel |
220*110*10 |
|||||
Groove Steel |
280*82*7.5 |
|||||
steel plate |
25mm*400mm |
|||||
round steel |
63 |
|
|
|
||
Technical parameters of whole machine | ||||||
Overall dimension of machine |
2500*900*1600mm |
|||||
Shear sword’s length |
700mm |
|||||
Largest Blade Opening(mm) |
350mm |
|||||
Machine weight |
About 3.4T |
|||||
Shipping Dimensions(standard container) |
1/2*20′GP |
|||||
Oil tank capacity |
250L |
|||||
4.Contact information:
If you need further information, please contact us freely, we will do our best to cooperate with you.
