Submerged Membrane Module Membrane Bioreactor MBR
The Submerged Membrane Module Membrane Bioreactor MBR is a combined technology of activated sludge process and membrane solid-liquid separation process.
- Easy to clean
- High efficiency / Low maintenance
- Membrane modules are back flushable
- Yield 60-80% less sludge than conventional system
- Compact design – footprint 75% smaller than conventional
- Possibility of direct and indirect water reuse
Membrane Bioreactor MBR sheet (pcs.)
Parameters | BN90 | BN150 |
Effective membrane area (m2) | 0.9 | 1.5 |
Overall size(B*H)(mm) | 510*1030 | 510*1650 |
Membrane pore size(μm) | 0.2~0.4 | |
Membrane material | PTFE | |
Water yield (L/pcs·day) | 450~630 | 750~1050 |
Effluent turbidity (NTU) | <1.0 | |
Suspended solids in effluent (SS,mg/L) | <1.0 | |
Model (All customized models are available by online inquiry)
Parameters | BN90-100 | BN90-150 | BN150-100 | BN150-150 |
Number of membrane elements (pcs.) | 100 | 150 | 100 | 150 |
Effective membrane area (m2) | 90 | 135 | 150 | 225 |
Treatment capacity (m3/d) | 45 | 67.5 | 75 | 112.5 |
Aeration capacity(m3/min) | 1~1.2 | 1.5~1.8 | 1.5~2 | 2.25~3 |
Frame material | Stainless steel 304 | |||
Diffuser pipe material | Stainless steel 304/UPVC/ABS | |||
Collection pipe material | UPVC | |||
1. [Q]How to buy my ideal products?
[A] Provide us with details about your water sources, water quality, flow rate and ground area, we will analyze for you and recommend you the best water treatment solution.
2. [Q]How to change the membrane sheet?
[A]Due to unique design of the flat membrane module, flat membrane can be replaced one sheet for one time, without changing support.
3. [Q]How to clean/wash the membrane sheet?
[A]You can clean the membrane cartridges in-situ: stop the blower and switch valves, pour the chemical for 10 minutes, keep intact for a few hours.
4. [Q]How often should the membrane be washed?
[A]Usually chemical cleaning should be carried out every half a year.
5. [Q]How to install after the equipment arriving destination?
[A]We will provide detailed illustrations to you. If necessary, we will send technicians to help you.
BENENV has clients in over 37 countries!
