Product Details

Condition	New	Type	Dry Cabinet
Place of Origin	Henan, China	Brand Name	TAIZY
Model Number	TZ	Voltage	380V
Power(W)	9.7KW	Dimension(LWH)	138029502200mm
Weight	2T	Certification	ISO CE
Warranty	12 months	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

high efficiency and have stock wheat dryer 0086-13503826925

1.Series range of wheat dryer

Paddy drier series ranging from 5HRL-3.0T to 5HRL-30.0T.

3.Speciality of wheat dryer

a.Full Automatic Computer Controlled.

b.Operation System Voice Reminder.

c.Networked Remote Fault Diagnosis.

d.Auto-determination of Tonnage.

2.Our Innovation of wheat dryer

Circulation Paddy Drier,pioneer invention in domestic -The world adavanced technology was adopted ,such as Operation System voice reminder,Full Automatic computer controlled, Failure Alarm display and Auto-stop Control(including detecting the flames of burner,auto-stop when fault occcurs) and Auto-setted tonnage etc. The equipment is fitted with internet interface and one key for operating whole mechnical process is available ,also with the function of the internet remote manipulation and fault detection and debug,especially for the technology of spare appliance electricity-controlled system,which is unique in the whole world.(when failure occures in operating appliances, the spare controlled system will start to ensure the safety operation of paddy drier).

3.Our advantages of wheat dryer

a.Automatic continuous operation,Stable performance, high efficiency.

b.Easy for operation,learning and maintenance.

c.Energy saving,environmentally-friendly, non pollution.

d.Our main appliances adopt the top brand with best and reliable quality.

4.The Technical Parameter of wheat dryer

Chart1.Technical parameters:
Model No.			TZ-10
Classification
Paddy types & Processing Qty	Paddy		10000
	(Capacity=560kg/m3)
	Wheat		12000
	(Capacity=680kg/m3)
Drying chamber cubage: m3			18
The weight of complete appliance(kg)			1950
Blower	Model		T4-72
	Mode		Centrifugal
	Outlet Diameter(mm)		φ580
	Speed(r.p.m )		1450
Burner	Model		BT14LRF
	Form		Hot blast stove (Double gun sprayer) or heat to 50KV by electricity
	Ignition Mode		Auto ignition
	Oil Consumption(L/h)		3.0~12.0
Fuel Type			Kerosene or 0#Diesel
Oil tank capacity (L)			80
Power Required	Rated Voltage (V)		Three phase 380~50Hz
	Rated output power	Motor(kW)	1.1
		Blower(Kw)	4.0
		Grain discharge motor(kW)	0.06
		Dust exhausting equipment(kW)	0.55
		Burner(kW)	0.014
		Moisture meter(kW)	0.008
		burner wind(kW)??	0.095
		Grain Discharge Gate(kW)	0.016
		Control Box(kW)	0.02
		below auger motor	1.1
	Motor total power(kw)		6.693
Features	Paddy feeding time	Paddy(min)	44~49
		Grain(min)	40~45
	Paddy discharging time	Paddy(min)	50~60
		Grain(min)	40~50
	Precipitation per hour	Paddy(%/h)	0.4~0.7
		Grain(%/h)	0.5~1.0
	Drying Capacity (t·%h)		≥5.50(paddy)
	Processing Capacity (kg/h)		≥500(paddy)
	Unit heat consumption (Kj/kg water)		≤5800(paddy)

Devices	Safety Device		Full filled Alert Automatic alarm (Failure,Overtemperature)& automatic shutoff, temperature control device, Overloading, Leakage protection, fire extinguisher
	Standard Device		Moisture detector Dust exhauster Ladder Grain discharge gate Dosing Device
	Control Box Device		7”TFT color screen touch remote manipulation System voice instruction
