Quick Details
| Type: | Hollow Block Making Machine | Brick Raw Material: | Cement | Processing: | Brick Molding Machine |
| Method: | Hydraulic Pressure | Automatic: | Yes | Capacity: | 70000-76000pcs/day |
| Place of Origin: | Henan China (Mainland) | Brand Name: | shuliy | Model Number: | QTY8-15 concrete brick moulding machine |
| Power: | 42.6kw | VIbrating frequency: | 5000-5500/min | Exciting Force: | 55kn |
| Carriage size: | 1020x900 | Forming cycle period: | 12-18s | Main machine power: | 37.1kw |
| Weight: | 14T | Workshop area: | 150-200m2 |
Packaging & Delivery
| Packaging Detail: | wooden case |
| Delivery Detail: | within ten days after payment |
Specifications
concrete brick moulding machine
1.skype:shuliy6641
2.2 mould for free
3.TT,L/C,ISO&CE.
concrete brick moulding machine/concrete interlocking making machine QTY8-15 machine to make concrete blocks
QTY8-15 concrete brick moulding machine
A:Production capacity of QTY8-15 concrete brick moulding machine
B:Technical parameters of QTY8-15 concrete brick moulding machine
Main machine size |
48000x22000x3000mm |
|
Pallet size |
1020x900mm |
Main machine power |
37.1kw |
|
Weight of machine |
14Ton |
Test pressure |
16Mpa/cm2 |
|
Mixer |
JS750 |
Vibration forece |
55kn |
|
Belt conveyor |
8m |
Forming cycle |
12-20seconds |
|
Voltage |
380v/3phase |
C:QTY8-15 concrete brick moulding machine
1. Area: Workshop area: 150-200m2, all factory area 3000m2, the bigger, the better.
2. Workers : five.
3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.
4.hollow block weight::
(390*190*190) :17KG,(190*140*190):13.5KG,(390*90*190):10KG
5. raw material consumption per day:200-260T
6. water consumption per day:3%-5% of raw material Weight.
D.QTY8-15 concrete brick moulding machine guarantee:
Our hollow block making machine is of one year guarantee,during the period we could supply spare parts if they are broken.
