Help CenterFly Ash Bricks Manufacturing Machine JKB40-35 Brick Moulding Machine//0086-18203652053
Related Products
-
Widely Used Concrent Block Making Machine/brick MachineNegotiableMOQ: 1 Set -
White Wall Machine/automatic White Wall Machine//0086-18203652053NegotiableMOQ: 1 Set
-
Low Price and Good Quality Clay Brick Making Machine,hollow Block Machine //0086-18203652053NegotiableMOQ: 1 Set
-
Brick Making Machinery/sement Block MachineNegotiableMOQ: 1 Set
-
High-Tech ! QT6-15 Cement Block Machine/cement Block Making Machine PriceNegotiableMOQ: 1 Set
Quick Details
| Condition: | New | Type: | fly ash bricks manufacturing machine JKB40-35 brick moulding machine |
Brick Raw Material: | sandy soil, fly ash, river silt etc. |
| Processing: | Brick Production Line | Method: | Vacuum Extruder | Automatic: | Yes |
| Capacity: | 10000-16000pcs/hour | Place of Origin: | Henan China (Mainland) | Brand Name: | shuliy Machinery |
| Model Number: | JKB40-35 | Voltage: | 220/380V | Power: | 75+110KW |
| Dimension(L*W*H): | 6000*1980*1980mm | Certification: | CE/SGS/ISO9001 | Warranty: | One to five years after shipment |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Brand of solid brick machinery: | shuliy Machine | Capacity of solid brick machinery: | 8000-11000pcs/hour |
| extrusion pressure: | 2.0-3.0Mpa | Vacuum degree: | less than 0.094 | Working method: | Vacuum extruder |
| Brick kinds: | Solid blocks | Power of motor: | 75+90KW | Raw material: | Fly ash/sandy soil, river silt, coal gangue |
| Model No.: | JKB40-35 | Weight: | 4T |
Packaging & Delivery
| Packaging Detail: | wooden case |
| Delivery Detail: | within ten days after payment |
Specifications
1.Certificate: CE/Iso9001:2008
2.fly ash bricks manufacturing machine
3.Use fly ash, sandy soil etc. as raw material
Fly ash bricks manufacturing machine JKB40-35 brick moulding machine
1. Specifications of fly ash bricks manufacturing machine JKB40-35 brick moulding machine
a. fly ash bricks manufacturing machine JKB40-35 brick moulding machine The primary extruder is without mixing system.This machine is also single stage structure which makes the whole set compact and reasonable.Mixing by machine saves time and effort.The raw materials agitation is relatively uniform which makes the end bricks color and quality of qualitative improvement.
b. fly ash bricks manufacturing machine JKB40-35 brick moulding machine Simple extruder with mixing box or not belongs to the first generation.The next stage came with the application of vacuum technology.A vacuum chamber is added before extruded portion.The operators can see the internal workings via the side observation room.This is a true stage of quality improvement.After vacuum stage,the intensity of the mud is much strengthened.Soft mud pieces need second setting but the bricks made by the vacuum extruder can burned directly after cutting.This is also a milestone of reducing the production cost.
c. fly ash bricks manufacturing machine JKB40-35 brick moulding machine Double stage is another upgrade of clay brick extruder.You can combined it into T structure or straight structure.The auger of the machine is coated with wear resistance metal.This machine is suitable for producing all kinds of cellbrick with material of gangue,shale,fly ash as well as clay.
2. Parameters of fly ash bricks manufacturing machine JKB40-35 brick moulding machine
2.1 capacity: 10000-16000pcs/hour
2.2 Motor power: 75+110KW
2.3 Extrusion pressure: 2.0-3.0MPa
2.4 Vacuum degree: less than 0.094
3. Photos related to fly ash bricks manufacturing machine JKB40-35 brick moulding machine
4. fly ash bricks manufacturing machine JKB40-35 brick moulding machine parameters as following
Model |
JKB |
Production capacity (pieces/h) |
10,000~14,000 pieces (standard brick) |
Extrusion pressure (Mpa) |
≥4.0 |
Required power (KW) |
Upper stage: Y280M-6-55 |
Lower stage: Y315M-6-132 | |
Vacuum pressure |
≥-0.092 |
Main shaft speed (rpm) |
Upper stage: 38rpm |
Lower stage: 25rpm | |
Shaping moisture content (wet basis %) |
16 ~ 20 |
Raw material plasticity index |
7 ~ 15 |
Required reducer |
Upper stage: ZLY600D i=10.89 |
Lower stage: ZLY960B i=15.95 | |
Required V-belt |
Upper stage: 7-SPB-4700 |
|
Low stage: 9-SPC-5500 |
Required vacuum pump (water circulation type) |
2SK ~ 6 ~ 2SK-12 |
Required electric motor |
Y15 ~ 22KW |
Overall dimension mm length × width × height |
5,300×5,550×2,510 |
