Dry Pet Food Puffing Machine
1. The body shell of pet food puffing machine is made of stainless steel material, to avoid getting rusty.
2. The machine consists of feeding system, extruding system, peeling systems, heating system, transmission system, control system.
3. It adopts advanced screw extrusion technology, the material can be formed through high temperature and high ressure pressure to extrusion molding.
4. With frequency control, it ensures the stability of the production process.
5. Can record the working condition so that to print it out.
6. The extruder can produce puffing food, floating fish feed, pet food.
Lab Using Pet Food Puffing Machine
| Model | Feeding power | Motor power | Cutting power | Heating power | Oil pump power | Capacity | Dimension |
| AZSPH-32 | 0.18kw | 4-7.5kw | 0.25kw | 2.1-3.5kw | 0.12kw | 10-15kg/h | 2.5x0.6x1.5m |
We have 3 capacity: 100-150kg/h, 200-300kg/h, 300-500kg/h. The floating fish feed and pet food line consists of 7 units of machines.
- Mixer
- Screw conveyor
- Twin screw extruder
- Air conveyor
- Electric oven for drying
- Flavoring line
Model |
AZSPH-56 |
AZSPH-70 |
AZSPH-85 |
Voltage |
380V/50HZ |
380V/50HZ |
380V/50HZ |
Installed Power |
66.84 kw |
97.65 kw |
146.65 kw |
Real Power |
47.84 kw |
76.65 kw |
97.05 kw |
Output Capacity |
100-150 kg/h |
200-250 kg/h |
300-500 kg/h |
Installation Size |
17.0 x1.2x 2.5 m |
18.0 x1.2x 2.5 m |
22.0 x1.2x 2.5 m |
Workers Required |
1 ~2 workers |
1 ~2 workers |
1 ~2 workers |
The pet food puffing machine can produce fish feed and pet food with different shape, only need to change the mould, The shape of mould can be made according to your request.
1. The pet food puffing machine will be sent to you by sea, by air or even by International courier service.
2. The dievery time is usually 20-25 days upon receipt of your depoist or LC.
1. The warranty time is one year from the date you get the machine, except the easy-wear parts.
2. If any parts are found defective in quality in the first year, we shall replace it freely.
3. We are responsible for the smooth operation of the machines. If you have any problem during production, just feel free to contact us. We assure you our soonest response.
Zhengzhou Azeus Machinery Co., Ltd is a professional supplier of the different kind of machinery. Our products has been exported to all over the world, Especially to Europe, North and South America, Africa, East and South Asia, Australia, New Zealand, etc.
Through our joint efforts, we have gained good reputation from our clients in communication, products quality, delivery, after-service, and other aspects.
We are looking forward to establishing a long-term and mutual-benefit business relationship with all of you. We will assure you our competitive price with better quality and service. We believe you will get what you expect from our company.
We accept different method for payment, just like TT, LC, escrow. You just need to choose one which is conveninet and safe for you.
Please do not hesitate to contact BELLA WU, if you need any more information or have any other questions. We will be at your service at any time.
