Stainelss Steel Dog Food Making Machine With Wheels

Stainelss Steel Dog Food Making Machine With Wheels photo-1
US$ 5,000 - 50,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Henan, China
Brand Name:
AZEUS
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao China
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Place of Origin Henan, China
Brand Name AZEUS
Model Number AZSPH-56
Application Cat
Voltage 380V
Power(W) 16KW
Dimension(L*W*H) 2000x750x1600mm
Certification CE
Warranty 1 year
After-sales Service Provided No overseas service provided

Stainelss Steel Dog Food Making Machine With Wheels

Product Description

1. The body shell of dog food making machine is made of stainless steel material, to avoid getting rusty.

2. The machine consists of feeding system, extruding system, peeling systems, heating system, transmission system, control system.

3. It adopts advanced screw extrusion technology, the material can be formed through high temperature and high ressure pressure to extrusion molding.

4. With frequency control, it ensures the stability of the production process.

5. With automatic oil lubricating system, to prolong the using life.

6. The extruder can produce puffing food, floating fish feed, pet food.

Dog food making machine parameter

ModelCapacityInstalled powerReal powerDimension
AZSPH-56100-120KG/H23KW16KW2000X750X1600mm
AZSPH-65150-180KG/H46KW30KW3500x1000x2000mm
AZSPH-70200-250KG/H60KW45KW3600x1000x2000mm
AZSPH-85300-500KG/H95KW80KW4500x1200x2300mm
Product Overviews

Stainelss Steel Dog Food Making Machine With Wheels



Stainelss Steel Dog Food Making Machine With Wheels

Process Flow Chart

  Stainelss Steel Dog Food Making Machine With Wheels



We have 3 capacity: 100-150kg/h, 200-300kg/h, 300-500kg/h. The floating fish feed and pet food line consists of 7 units of machines.

  1. Mixer
  2. Screw conveyor
  3. Twin screw extruder
  4. Air conveyor
  5. Electric oven for drying
  6. Flavoring line

 Model

AZSPH-56

AZSPH-70

AZSPH-85

Voltage

380V/50HZ

380V/50HZ

380V/50HZ

Installed Power

66.84 kw

97.65 kw

146.65 kw

Real Power

47.84 kw

76.65 kw

97.05 kw

Output Capacity

100-150 kg/h

200-250 kg/h

300-500 kg/h

Installation Size

17.0 x1.2x 2.5 m

18.0 x1.2x 2.5 m

22.0 x1.2x 2.5 m

Workers Required

1 ~2 workers

1 ~2 workers

1 ~2 workers

Finished Products

The dog food making machine can produce fish feed and pet food with different shape, only need to change the mould, The shape of mould can be made according to your request.

Stainelss Steel Dog Food Making Machine With Wheels
