We are a professional trading company and our products exported to Europe,USA,Middle East,Asian etc. We can offer crusher,mixer,bagging machine,sterilizer,clean bench,fermentation tank,dryer etc system machine
and liquid or solid culture.
Sterilizer component
| Main Body | Pressure vessel, soft water tank,supporter,spray device,pipe |
| Water Recycle Part | Pump,spray pipe, valve, |
| Control Part | PLC,touch screen,switches,contractor,breaker,switch and buttons,solenoid value,air filter |
| Safety Part | Interlock device,safe value,air circult check value,alarm indicator |
| Record Part | Paper recoder |
Technical parameter:
| Main material | Lined stainless steelQ(345B) |
| Specification | 2*2*10m |
| Body thickness | 10mm |
| Capacity | 30-35m3 |
| Design presure | 0.3-0.5Mpa |
| Working presure | 0.2-0.4Mpa |
| Design temperature | 140 degree |
| Working temperature | 135 degree |
| Working efficiency | 7000bags/17*35 |
| MQQ | 1 set |
Performance:
1>The sterilizer equipment has particular pipeline design and advanced control programs,which make sure quick heating,good penetrability as well as save energy.
2>The body of mushroom sterilize is pressed with special stainless steel material into rectangular structure.There are two doors, one is connected with bagging room , another is connected with inoculation room, which convenient to put and take out the cultivation bag and improve the working efficiency.
3>The sterilize has character of advanced technology, flexible setings,easy operation,high degree of automation.According to mushroom types, you can set different parameters.It has its own recorder system and will keep it for many years.
