As a professional producer for mushroom equipment,we can supply you the bag grow system equipment,bottle grow system equipment and rack grow system equipment. Bag grow system equipment include the sawdust crusher,mixer equipment,bag filling production line,autoclave steam sterilizer,clean bench, inoculation machine, fermentation cylinder,mushroom dryer machine etc.
The steam sterilizer mainly sterilize the compost bag and make aseptic environment for mushroom growth. We can supply round model and rectangle
model .Of course, the rectangle model is expensive, but its usage ratio is much higher than round model.
Autoclave sterilizer component
| Main Body | Pressure vessel, soft water tank,supporter,spray device,pipe |
| Water Recycle Part | Pump,spray pipe, valve, |
| Control Part | PLC,touch screen,switches,contractor,breaker,switch and buttons,solenoid value,air filter |
| Safety Part | Interlock device,safe value,air circult check value,alarm indicator |
| Record Part | Paper recoder |
Technical parameter:
| Main material | Lined stainless steelQ(345B) |
| Specification | 2*2*10m |
| Body thickness | 10mm |
| Capacity | 30-35m3 |
| Design presure | 0.3-0.5Mpa |
| Working presure | 0.2-0.4Mpa |
| Design temperature | 140 degree |
| Working temperature | 135 degree |
| Working efficiency | 7000bags/17*35 |
| MQQ | 1 set |
Performance:
1>The sterilizer equipment has particular pipeline design and advanced control programs,which make sure quick heating,good penetrability as well as save energy.
2>The body of mushroom sterilize is pressed with special stainless steel material into rectangular structure.There are two doors, one is connected with bagging room , another is connected with inoculation room, which convenient to put and take out the cultivation bag and improve the working efficiency.
3>The sterilize has character of advanced technology, flexible setings,easy operation,high degree of automation.According to mushroom types, you can set different parameters.It has its own recorder system and will keep it for many years.
Sterilizer capacity often decided based on compost bag size and basket dimension. As usual, basket capacity:12bags/basket and 16bags/basket. Once confirm basket capacity, the size will be confirmed. When we design the cart, we should consider the compost bag height and basket size. All are confirmed, we will count out the sterilizer capacity according to cart quantity.
Loading photos
When we decide the sterilizer capacity, we not only consider the farm scale demand, but also consider the loading condition. Please note: 20 foot container:2.35m height and 2.35m width ; 40 foot high container:2.69m height and 2.35m width. In order to load the sterilizer into container, the inner size of sterilizer should be: inner width, 1.65m and inner height: 2.0m. Once above the size, it will be difficult to load into container. Only way to book open-top container, but it will be high freight.
