pharmaceutical equipment (two-stage reverse osmosis)
The original water (tap water, surface water, underground water) is sent to pretreatment system by adding pressure to be filtered roughly, then to be filtered by sophisticated filter, and the water is transmitted to primary reverse osmosis by one-stage high pressure pump to be filtered, then the water is add pressure again by secondary high pressure pump and sent to second reverse osmosis system to produce the product water, this source is called two-stage reverse osmosis.
Raw water conductivity>500us/cm; purified water conductivity:1—10us/cm
optional equipment
1) RO membrane:
2) Pump:
3) Ozone system
4) UV sterilizer
5) SS304 water storage tank
6) Chemical dosing system
RF-ZERO-3000L/H | |
Parameter index | |
Product |
Integrated purified producing unit (two-stage) |
Model |
RF-ZERO-3000L/H |
Productivity |
3000Liter/ H(25°C) |
Input water quality |
TDS≤2000PPM |
Desalting rate |
≥97% |
Recycling rate (purified water;outlet water) |
50~65% |
required temperature |
5~35°C |
Standard rated power |
|
Water Pretreatment part | |
Quartz Stand filter |
SUS304 stainless steel tank |
Active Carbon filter |
SUS304 stainless steel tank |
Softner |
SUS304 stainless steel tank |
Sophisticated filter |
Sus304 stainless steel tank and 5μm, 30 inches and 5 pieces of filter cartridges |
High pressure pump |
China nanfang |
Multi-stage pump |
China nanfang
|
RO Treatment part | |
membrane |
8040 RO Hydranautics membrane ,7 pieces of filter cartridges |
Shell |
SUS304 stainless steel |
Accessories | |
material |
SUS304 stainless steel |
Electronic parts |
pragrammable logic controller |
Device for option |
Chemical measurement system ,uv sterillizer,ozone generator,The built-in membrane washing device. |
Ruifei had provided turn key scheme and solutions for customers, and also provide consultation and other information about tofu, soy milk and food process. We assure that:
- workers trainning, false solution.
-
Replace and install parts unless the need to replace arises in the opinion of the
Seller from any mistake or misuse by the end user. - Replace and install or repair any Products which the manufacturer accepts as defective.
- Respond orally to requests for technical assistance from the end user within 24 hours, and where necessary provide technical intervention within 5 working days.
Our company has rich experience to help customers to establish the different production lines for different use, for example: Soybean Processing Plants. Our Web: . We can arrange technical staff to help customer set up whole production line for mineral water, pure water. Coca-cola, milk, juice and vinegar,oil, we are profession for making it. If anyone who is interested in such field wants to buy the whole equipments and machines, pls contact us freely.
We warmly welcome customer to visit our factory at any time, you will see the machine working and running condition in our factory!
