Tunnel Talcum Powder Microwave Drying Sterilization Machine--SS304

Tunnel Talcum Powder Microwave Drying Sterilization Machine--SS304 thumbnail-1
Tunnel Talcum Powder Microwave Drying Sterilization Machine--SS304 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Drying Oven
Place of Origin:
Shandong, China
Contact Supplier Request Quote Chat Now
Shandong Adasen Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Drying Oven
Place of Origin Shandong, China
Brand Name ADASEN
Model Number JN-30
Voltage 380V
Power(W) 30KW
Dimension(L*W*H) 10680*1410*1750mm
Certification CE
Warranty 12 months

Specifications

tunnel conveyor microwave drying sterilization machine for talcum powder
1 save energy
2 easy to control
3 SS304,with CE

Industrial Tunnel Conveyor Belt Type Microwave Drying Sterilizing Machine for Talcum Powder:



Usage:

The equipments are used for the rapid desiccation of power ,granular,pasty materials,such as Glass fiber, chemical raw materials, cellulose (eg hydroxyethyl cellulose, carboxymethyl cellulose, etc.), mannitol, nickel hydroxide, lithium cobalt oxide, graphite, carbon brushes, silicon carbide, calcium chloride dihydrate, activecarbon, zirconium oxychloride, zirconium oxide, copper oxide, aluminum oxide, zirconium hydroxide, zirconium carbonate, copper carbonate, manganese carbonate, is zirconium sulfate, ammonium zirconium carbonate, zirconium silicate, zirconium potassium carbonate, oil-based ink drying agentcross-linked anti-agent, water-based ink, expandable graphite, a variety of ceramic zirconium oxide, iron oxide, cobalt oxalate etc.Water content from 40% to 0.5% after drying ,drying time only need 5~6 minutes,temperature can be controlled in 0~200celsius degrees.



Features:

Moisture of chemical products is very low in general,such as ammonium chloride (1%),products purple(4%)have drying process in the production .



Traditional crafts often use steam-heated drying,long production cycle,dried quality is poor,such as copper sulfate,although centrifugal dewatering,but there is still a small amount of absorbed water stained ,in order to dehumidify these stained water ,while heating using steam ,must evaporate absorbed water and copper sulfate materials,require more heat to complete the drying task.Microwave heating features:



1 Penetrating whole heating,microwave can penetrate material internal,heating inside and outside at the same time,the heating rate is very fast;



2 Selective heating,due to the different electrical characteristics of material media,water and material have different microwave absorption capacity,microwave is preferred role to the materials that have strong absorption ability.



Use microwave heating characteristics,not only can shorten the production cycle,improve product quality,save energy(efficient),but also can improve the working environment,there is no dust pollution.Therefore, chemical products drying is playing advantages of microwave heating and drying technology.



Technical Parameters:



Model

Rated input power(KVA)

Microwave output power(KW)

Expected dehydration(kg/h)

Expected sterilization capacity(kg/h)

Dimension

L*W*H(mm)

JN-12

18kw

12kw

12~17

150~200

7290*840*1750

JN-15

21kw

15kw

15~21

200~250

8420*840*1750

JN-18

26KW

18KW

18~22

230~280

8420*840*1750

JN-20

28kw

20kw

20~28

280~350

9550*840*1750

JN-25

36kw

25kw

25~35

350~400

9550*840*1750

JN-30

42kw

30kw

30~42

400~480

10680*840*1750

JN-35

49KW

35KW

35~45

480~550

10680*840*1750

JN-40

56kw

40kw

40~48

550~650

10680*1410*1750

JN-45

63KW

45KW

45~52

600~700

11810*1410*1750

JN-50

70kw

50kw

50~60

700~800

11810*1410*1750

JN-60

84kw

60kw

60~84

850~1000

12940*1410*1750

JN-70

98kw

70kw

70~~98

1000~1100

14070*1410*1750

JN-75

105kw

75kw

75~105

1100~1200

15200*1410*1750

JN-80

112kw

80kw

80~112

1200~1400

15200*1600*1750

JN-100

140kw

100kw

100~140

1400~1600

15200*1665*1750

JN-120

168kw

120kw

120~168

1600~2000

17460*1665*1750

JN-150

210kw

150kw

150~210

2000~2500

20850*1750*1750

NOTE: We can specially design the equipment according to your products’ features.





 Tunnel Talcum powder microwave drying sterilization machine--SS304
